450nm 3W Fiber Coupled Laser Diode Module

Categories Fiber Coupled Laser Diode
Brand Name: SkyEra
Model Number: 3W 450nm
Certification: CE
Place of Origin: China
MOQ: 1
Price: Can be negotiation
Payment Terms: L/C, D/A, D/P, T/T
Brand: SkyEra
Output power (W): 3W
Local Service Location: None
warranty period: 1 year
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

450nm 3W Fiber Coupled Laser Diode Module


Product specification

ParameterMinTypMaxUnitConditions
Output Power-3-W

Centre Wavelength T1

445

450

455

nm

Spectral Width (FWHM)-37nm
Threshold Current-0.25-A
Operating Current-2.653.0A
Operating Voltage-4.65.5V
Convention Efficiency-20-%
90% Power-0.13-NA
Wavelength shift vs. Temperature-0.1-nm/℃
Slop Efficiency-1.0-W/A
Storage Temperature-30-70°CNon-Condensing
Operating Temperature152025°C
Fiber Bend Radius37.5--mm
Buffer Diameter-250-μm
Cladding Diameter-125-μm
Core Diameter-105-μm
Numeric Aperture-0.15-NA
Fiber Connector-CO-SMA905,FC,ST
