1450mm Paper Waterbase UV Varnishing Machine Spot Coating

Categories UV Varnishing Machine
Brand Name: ECOOGRAPHIX
Model Number: ECOO SD1450
Certification: CE
Place of Origin: CHINA
MOQ: 1SET
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 500SETS
Delivery Time: 30DAYS
Packaging Details: Standard Export Packing
Max. laminating Sheet (mm): 1100X1450mm
Min Sheet Size: 350x460mm
Power: 47KW
Coating speed (m/min): 8000s/h
Machine weight (kgs): 9500KGS
Condition: New
Application: Water-based Varnish ,UV Varnish
Warranty: One Year
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1450mm Paper Waterbase UV Varnishing Machine Spot Coating

UV Spot Overall Coater Varnishing Machine 1450mm


The HIS series of UV local glazing machine adopt the Bite-transferring structure and chain track design of offset printing press. The drying section is a conveyor net structure, adopt the large diameter impression cylinder, so the finished oil film is very flat and even, accurate and bright. It can comprehensive think about both thick and thin papers, and can be used for both full UV and partial UV coating.


PRODUCT DESCRIPTION
* The machine is suitable for using water-based glue, solvent-based glue, and thermal film.
* Cold-water non-curling system: The paper will be non-curling after separated.
* Low cost: Ceramic anilox roller coating, minimize gluing amount to 5g/sqm.
* The heating energy cycle drying system makes the whole machine power consumption about 15kw/h.
* High efficiency:The machine working speed reaches to 70m/min, 8000sheets/h.

Remarks:
Laminating speed depend on paper weight, film thickness and gule material quality.
Subject to change without notice.
Standard Configuration: Selectable Configuration:

Auto Feeder

Multifunctional Coating Unit

UV Curing System

Auto Delivery Unit

Auto Control


High Speed UV Spot and Overall Varnish Coating Machine
ModelEcoo HIS-1450
Max.sheet size1100x1450mm
MIN.sheet size350X460mm
Max.coating size1090x1440mm
Max coating thickness0.025mm
Sheet thickness128-600gsm
Coating registration accuracy±0.2mm
Production speed6200sheets/hour
Weight9500kgs
Dimension12230x3100x1844mm
Power57KW(E) 47KW(W)
Remark: Production speed depending on sheet weight, size and quality
