| Categories | Lithium Polymer Battery Cell |
|---|---|
| Brand Name: | RESKY |
| Model Number: | LP10542125 |
| Certification: | CE,ROHS,MSDS,UN38.3 |
| Place of Origin: | China |
| MOQ: | 10PCS |
| Price: | 6-10USD |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 50000PCS/DAY |
| Delivery Time: | 10-12Workdays |
| Packaging Details: | Paper box |
| Norminal capacity: | 6000mAh |
| Working voltage: | 3.7v-22.2v |
| Con Discharging Current: | 25C |
| Max Discharging Current: | 50C |
| Weight: | 128g |
| Internal resistance: | 2Ω |
| Size: | 10.5*42*125mm |
| Warranty: | 12months |
| HS Code: | 8507600090 |
| Connector: | Xt60, Xt90, T-Type, Anderson, Bullet |
| Company Info. |
| Shenzhen Resky Electronics Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Product Description
Lipo Battery 10542125 3.7v 7.4v 11.1v 14.8v 6000mAh 20C Rechargeable Lithium Polymer Battery Pack
| NO. | Items | Specifications |
| 1 | batteries | 3.7V 6000mah lipo battery |
| 2 | Charge voltage | 4.2V |
| 3 | Nominal voltage | 3.7V |
| 4 | Nominal capacity | 6000mAh 25C Discharge |
| 5 | Charge current | Standard Charging:0.2C Rapid charge: 25C |
| 6 | Standard Charging method | 0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C |
| 7 | Charging time | Standard Charging:2.75hours(Ref.) Rapid charge: 2hours(Ref.) |
| 8 | Max.charge current | 0.5C |
| 9 | Max.discharge current | 50.0C |
| 10 | Discharge cut-off voltage | 2.5V0.25V(0.2C) |
| 11 | Operating temperature | Charging: 0 °C ~45 °C Discharging:0 °C ~45 °C |
| 12 | Storage temperature | -10°C~ +45 °C |
| 13 | Dimension | Length:125±0.5mm (not including tabs) Width:42±0.5mm Thickness:10.5±0.2mm |
| 14 | Drop Test | The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage |
| 15 | cycle time | ≥500times |
Features:
Capacity and Voltage:
Capacity: Measured in milliampere-hours (mAh), this determines how long the RC vehicle will run per charge. A higher mAh rating means longer run time.
Voltage: Determines the speed and power of the RC model. The voltage of a battery pack is the sum of the voltages of its individual cells. For example, a 2S LiPo battery pack has two cells in series, providing a voltage of around 7.4V.
Safety and Maintenance:
LiPo batteries, in particular, require careful handling to avoid overcharging, over-discharging, and short-circuiting, which can lead to fire or explosion.
It is recommended to use a charger designed for the specific type of battery and to regularly monitor the battery's health and performance.
Performance Over Time:
RC batteries gradually lose performance over time, manifesting as decreased voltage and reduced run time. Proper care and maintenance can extend the lifespan of the battery.
