Single Port 100Mb Integrated Magnetics Network Jack Rj45 POE Connector

Single Port 100M PoE RJ45 Integrated Connector , RJ45 Network Connector

Key Features

• Available for 2.5GBASE-T, 5GBASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T, HDBASE-T Speeds
• RoHS Compliant
• Top and Side-Entry PCB Mount Options Available
• Multiple Package Options Available, 1x1, 1xN, 2xN, RJ45/USB, Low Profile, Offset & more.
• THT, Press Fit, Pin-In-Paste, SMT Options
• Higher Isolation (TVSS, Surge)
• Extended Temperature -40°C to +85°C
• PoE, PoE+ & 4 Pair PoE Capable

Applications:

• Integrated RJ45 connector main used to :

• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,

internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,HomePNA,DSL／ADSL and so on.

For example:
