Monochrome White Color 0.63 Inch 120x28 Pixels OLED Display Module
Ultra-small passive matrix OLED display module with high contrast
and low power consumption, ideal for space-constrained
applications.
Technical Specifications
| Parameter | Specification |
|---|
| Product | 0.63 Inch OLED Display Module |
| Driver IC | SSD1312 Or Equivalent |
| Interface | I2C |
| Display Color | Monochrome (white) |
| Number Of Pixels | 120x28 Pixels |
| Display Mode | Passive Matrix |
| Drive Duty | 1/28 Duty |
| Panel Size | 21.54 X 6.62 X 1.22 (mm) |
| Active Area | 15.58 X 3.62 (mm) |
| Pixel Pitch | 0.13 X 0.13 (mm) |
| Pixel Size | 0.11 X 0.11 (mm) |
| Pin Number | 14 Pins (Can Be Customized) |
| Viewing Direction | All Viewing Angles |
| Connection | Soldering/Hotbar (customizable) |
| Life Time | 50,000 Hours @60cd/m2 |
Product Overview
This ultra-small passive matrix (PMOLED) single-color white display
module features a diagonal size of only 0.63 inches with a pixel
resolution of 120×28. Utilizing the dedicated SSD1312 driver IC
with standard I2C communication interface (14PIN FPC soldered
type), this module requires no additional backlight and features
self-illuminating pixels.
Size parameters: Module size 21.54×6.62×1.22mm, display area
15.58×3.62mm, thickness only 1.22mm, making it extremely
lightweight and thin, suitable for installation in very small
spaces.
Electrical and display characteristics: Typical operating voltage
2.8V, extremely low power consumption (VDD operating current
approximately 180μA), high contrast, viewing angle close to 180°
full viewing angle, fast response speed, and stable operation
within a wide temperature range of -40°C to +85°C.
Compatibility: The driver IC SSD1312 is highly compatible with the
instruction set of SSD1306, allowing direct adaptation to
mainstream MCUs such as Arduino, STM32, ESP32, Raspberry Pi, with
abundant development resources available.
Environmental compliance: Compliant with RoHS standards, containing
no harmful substances.
Core Applications
- Wearable Devices: Smart bracelets, sports watches, Bluetooth
headphones, status bars of smart glasses, displaying concise
information such as time, steps, battery level, Bluetooth
connection status
- Portable / Medical Health Devices: Mini blood pressure monitors,
pulse oximeters, heart rate monitors, insulin pumps, used to
display key physiological parameters and working status
- Smart Home and Internet of Things Terminals: Smart sockets, sensor
nodes, small controllers, remote control panels, showing working
mode, battery level, signal strength
- Audio and Portable Digital: MP3 players, voice recorders, miniature
radios, displaying tracks, volume, playback status
- Industrial Instruments and Embedded Devices: Small flow meters,
pressure sensors, vehicle-mounted miniature instruments, capable of
stably displaying data in narrow, vibrating, and
temperature-differential environments
- Maker DIY and Prototype Development: Suitable for rapid
verification of small electronic projects with strict size and
power consumption limitations
Packaging & Shipping
Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging methods vary
based on product size and customer requirements, with different
countries having specific requirements.
Shipping: Express services including DHL, Fedex, EMS, UPS, air shipping, and
sea shipping. Any preferred shipping method available.
Payment Method: Various payment options available.
Frequently Asked Questions
1. I want the LCD display 8 digits and the outline size is
65x30x2.8mm?
Answer: No problem. Please send us your specification/drawing
paper. If you don't have specifications, you can provide samples;
we will recommend suitable products if they are standard, or we can
customize based on your requirements.
2. This LCD is just what we want, but it is big size, do you have
any smaller size? And the display content need to be changed a
little.
Answer: For segment type LCD modules, if you need to modify the
outline size or display content, a new LCD glass module is
required. We will need to create new tooling for you.
3. This LCD display is HTN type, but I want STN type, can you make?
Answer: That's all right. We can change the type according to your
request.
4. I want to customize a new LCD module. Can you do?
Answer: Yes, we can. Please send your drawing paper. If you don't
have one, please provide the outline size of the LCD display,
display information (glass thickness, polarizer, display type,
connector mode, storage temperature, operating temperature, supply
voltage, viewing direction, drive condition), and we can customize
for you.
5. What is the lead time for tooling?
Answer: Generally, it takes 15 to 25 days after drawing paper
confirmation and tooling charge payment. We can provide the exact
time when you confirm the drawing paper.
6. Can you send us samples for checking?
Answer: Yes. Sample orders are available.
7. What is the Lead Time?
Answer: If we have stock for standard products, the lead time is
one day after payment. For mass production of special products, the
lead time is about 15-30 days. If we can finish earlier, we will
report the information in advance.
