Categories | Marine Diesel Engine |
---|---|
Model NO.: | Z12V190BC |
Engine: | 4 Stroke |
Engine Position: | Inboard |
Condition: | New |
Transport Package: | Wooden Cases |
Specification: | 3000KG |
Trademark: | Jichai |
Origin: | China |
HS Code: | 8408100000 |
Supply Ability: | 50000pecises/Year |
Package Size: | 270.00cm * 157.00cm * 210.00cm |
Package Gross Weight: | 5300.000kg |
Cylinders: | 12 |
Fuel Type: | Diesel |
Engine Capacity: | 4.1-5L |
Customization: | Available | Customized Request |
Shipping Cost : | about shipping cost and estimated delivery time. |
: | Initial Payment Full Payment |
Currency: | US$ |
Return&refunds: | You can apply for a refund up to 30 days after receipt of the products. |
Place of Origin: | china |
Certification: | ISO9001 |
MOQ: | 1 |
Price: | 10-1000 |
Packaging Details: | Wooden box and carton packaging |
Delivery Time: | 15 days |
Payment Terms: | TT,western |
Company Info. |
Jinan Guohua Green Power Equipment Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
Series 2000V marine diesel engines | |||||||
Model | Rated Power(kw/hp) | Rated speed(r/min) | Specific fuel consumption(g/kw'h) | Specific oil consumption(g/kw'h) | Overall dimension L*B*H(mm) | Net weight(kg) | |
Z12V190BC1 | 800/1080 | 1500 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Z12V190BC2 | 882/1200 | 1500 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Z12V190BC8 | 1000/1360 | 1500 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Z12V190BC9 | 882/1200 | 1500 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Z12V190BC10 | 900/1225 | 1450 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Z12V190BC11 | 882/1200 | 1500 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
G12V190ZLC1 | 1000/1360 | 1450 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
G12V190ZLC2 | 1000/1360 | 1450 | ≤209.4 | ≤1.6 | 2642*1588*2070 | 5300 | |
Main technical data No. and arrangement of cylinders:12,60.Vee Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:210mm Total displacement:71.45L Compression ration:14:1 Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication | |||||||
Model of generating set | Model of diesel engines | Model of generator | Rated Power KW | Rated voltage V | Rated frequency HZ | Overall dimension L*B*H(mm) | Net weight KG |
CCFJ400/1000 | Z12V190BCD-2 | TFC5454-6JH42 | 400 | 390 | 50 | 4210*1500*2260 | 10500 |
CCFJ630/1500 | Z12V190BCD | TFC5456-4JH42 | 630 | 390 | 50 | 4260*1500*2260 | 12000 |
![]() |
