| Categories | Custom PCB Assembly |
|---|---|
| Brand Name: | Leadsintec |
| Model Number: | PCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Place of Origin: | Shenzhen |
| MOQ: | 1pcs |
| Price: | Negotiable (Depends on your gerber and bom) |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union |
| Supply Ability: | 80000pcs/month |
| Delivery Time: | 1-30days |
| Packaging Details: | PCB: Vacuum Packing / PCBA: ESD Packing |
| Copper thickness: | 1/2OZ 1OZ 2OZ 3OZ |
| Product name: | Electronic PCBA |
| Base material: | FR-4 |
| Surface finishing: | HASL/OSP/ENIG |
| Solder mask color: | White Black Yellow Green Red |
| Application: | Consumer Electronics,Medium and Small Projects,Electronic products |
High Frequency Alum 30z Multilayer PCBA Electronics
Capable
Leadsintec offers one-stop service from PCB designing,
manufacturing, assembling, components soucing,programming to
testing.
Confidential and Nondisclosure Agreement
We protect the Intellectual Property for our customers in the whole
process. Our staff of trained professionals are all working under a
strict confidentiality contract and keep[ the business secrets.
Flexibility
Customers-oriented. We forever center on customers’ demands,
constantly update and introduce into technology, fully understand
customers’ requirements and offer our professional suggestion.
PCBA Capability
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
Min.thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) | ||
| Board thickness | Standard | (0.1-4mm±10%) | |
| Min. | Single/Double:0.008±0.004” | ||
| 4layer:0.01±0.008” | |||
| 8layer:0.01±0.008” | |||
| Bow and twist | 7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”(0.2mm) | |
| Drill deviation | ±0.002″(0.05mm) | ||
| PTH hole tolerance | ±0.002″(0.005mm) | ||
| NPTH hole tolerance | ±0.002″(0.005mm) | ||
Solder mask | Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″(0.07mm) | ||
| Thickness | (0.012*0.017mm) | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″(0.15mm) | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949,ISO9001 | ||
| Delivery time: | PCB | 3-12days | |
| PCBA | 8-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 450*450mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
Leadsintec is the best pcba factory in china for customers of industry, automotive, medical, military, aerospace, smart home, communication, which keep long-term cooperation with domestic and abroad clients over 20 years.
|
