Battery Metal Shell Nonstandard Helium Leak Testing Equipment

Helium Leak Testing Equipment For Battery Metal Shell With High Precision

Product information:

Our systems are based on a Mass Spectrometer Leak Detector that is connected to the vacuum line of a vacuum chamber. Helium is introduced inside the tested part. Any helium passing through a leak increases the helium partial pressure that is continuously monitored by the mass spectrometer.

The system consists at least of the following components:

A Mass spectrometer with its own vacuum system.

One chamber.

A vacuum group that evacuates the chamber thus reducing the helium partial pressure inside the chamber.

A valve manifold connected to the part that allows different steps of the detection routine (part evacuation, helium filling, helium exhaust, part venting…).

A power and control cabinet including touchscreen human operator interface.

Advantage:

Helium leak test equipment are the ideal solution for leak detection and leak-tightness testing under vacuum. The test gas Helium is safe and a small, light molecule which is suitable for detecting micro leaks. The detection range of Helium in vacuum tests lies between 10-2 and 10-13 Pa.m3/s. Helium leak detection is extremely accurate, quantitative and repeatable. Fast cycle times are a further advantage.Leak Testing Equipment

Parameter:

Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in R & D, manufacturing and sales of technology intensive industrial equipment. Its main products include laboratory testing equipment and production line detection system, which are widely applied to refrigeration, automotive, electric power industries, military, home appliances and other industries.

The company is led by Mr. Li Jianhe, an expert with profound knowledge in vacuum and automatic testing equipment. The company has its own core technology and a number of invention and utility model patents. Relying on a high-level talent team, the company adopts a new production mode focusing on development and design, assembly and debugging and after-sales service, and launches products suitable for its use and technical requirements according to different situations of customers. Since its establishment, the company has launched various types of special equipment to the market. While meeting the domestic market demand, the equipment is also exported to the Americas, Europe, Asia and Africa and other countries and regions. The pursuit of excellence and respect is the business philosophy and the highest guiding principle of the company's operation and management.

Our business goal is to rely on our technology to provide customers with excellent products and services. We will promote core competitiveness, create high performance, and build into the world's top brand in the field of automation and control.
