| Categories | Pilot Scale Spray Dryer |
|---|---|
| Brand Name: | YIGAN |
| Model Number: | YPG |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 set |
| Price: | negotiation |
| Supply Ability: | 10 sets per month |
| Delivery Time: | 20 working days after received your payment |
| Packaging Details: | Packed in film firstly, and then reinforced with wooden case for outer packing |
| product name: | Spray Dryer price |
| spraying mode: | pressure |
| feature: | granulation |
| product size: | 1mm |
| application: | compound fertilizer |
Compound fertilizer pressure spray dryer price granulation machine
Application
Compound fertilizer pressure spray dryer granulation machine is broadly used in food, pharmaceutical, chemical, dye, ceramics,
biological, pesticide, plastics and other industries. The following
are some specific applications
Spray Drying Granulation
Chemical industry: organic catalyst, resin, synthetic detergent,
oil, thiamine, dye intermediate, white carbon black, graphite and
ammonium phosphate.
Food: amino acid, spices, protein, starch, dairy products, coffee
extracts, fish meal and so on
Pharmaceuticals: Chinese patent medicine, pesticide, antibiotic and
dissolved medicines
Ceramics: magnesium oxide, porcelain clay, all kinds of metal
oxide, dolomite, etc.
Spray Granulation:
Fertilizers, alumina, ceramic powder, heavy metal, granulous
detergent and Chinese patent drug
Spray Cooling Granulation:
Aliphatic acid, paraffin, olein and oil
In addition, our spray drying machine can also be used in the
fields of spray crystallization, spray concentration and spray
reaction.
Features of Pressure Spray Dryer
1. The characteristics of this spray drying machine include fast
drying speed, high dust collection rate and energy conservation.
2. The dried products are in the shape of spherical particles, with
uniform particle size, good fluidity and solubility, high purity
and superior quality.
3. With wide range of applications, this pressure spray dryer can
not only implement hot air drying and granulation, but also conduct
cooling granulation, spray crystallization and spray reaction.
4. Compound fertilizer pressure spray dryer price granulation machine
is easy to operate and maintain. It is also easy to realize
automatic operation.
Technical parameters
| Model | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| Evaporated amount(kg/h) | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| d(mm)ΦxH | 1200x8900 | 1800x11500 | 2200x13500 | 2400x14800 | 2800x15400 | 3400x18800 | 4600x22500 |
| Power(KW) | 8.5 | 14 | 22 | 24 | 30 | 40 | 82 |
| Inlet air temperature(°C) | 300-350 | ||||||
| Water content(%) | <5(can reach to 0.5%) | ||||||
| Yield(%) | >97 | ||||||
| Heating by Electricity(KW) | 75 | 120 | |||||
| Evaporation and Electricity(Mpa+KW) | 0.5+54 | 0.6+90 | 0.6+108 | Temperature is below 200°C,calculating in accordance with pratical situation | |||
| Furnace(Kcal/h) | 150000 | 300000 | 300000 | 400000 | 600000 | 1000000 | 1500000 |
|
