| Categories | High-speed Disperser |
|---|---|
| Brand Name: | Chenglong |
| Model Number: | GFJ-B |
| Place of Origin: | China |
| MOQ: | 1 unit |
| Price: | Consultation |
| Supply Ability: | 50,00pcs/Month |
| Packaging Details: | Wooden box packaging or as per customer requirements |
| Applicable to: | Coatings, dyes, pigments, inks, papermaking adhesives, etc |
| Name: | GFJ-B Double-shaft floor-standing disperser |
| Product brand: | Cheng Long |
| Features: | The mixing and blending effect is excellent |
Product Description
GFJ-B series of double-shaft high-speed dispersers
The GFJ-B high-speed dispersion agitator is suitable for use in coatings, dyes, pigments, inks, papermaking, adhesives and other chemical industries for stirring, dissolving and dispersing liquid and liquid-solid phase materials
When stirring and dispersing, the air retention is extremely small, and the mixing and homogenization effect is excellent. For powder and granular materials, it can make the particles smaller. Its types include fixed-speed type, double-speed type and variable-speed type. The lifting of the stirring shaft is controlled by hydraulic pressure, and all operations are centralized in a dedicated electrical cabinet
Main technical specifications and parameters
| Item/modle | GFJ-B-600 | |
| Speed | Electromagnetic speed control | Frequency control |
| Main motor power(kw) | 30 | 30,45 |
| Speed of the dispersion axle(r/min) | 120-1200 | 0-1500 |
| Diameter of the dispersion disk(mm) | 300x2 | |
| Oil pump motor power(kw) | 1.5,2.2 | |
| Lifting height of the dispersion disk(mm) | 1000,1200 | |
| Volume of Ingredlents tank(L) | 1000-2000 | |
| Overall dimension Length x Width x Height (mm) | 2400x1000x2300 | |
| Weight(kg) | 1200 | |
Our company
A corner of the workshop
Corporate honors
|
