| Categories | Automotive Sensors |
|---|---|
| Brand Name: | Consensic |
| Model Number: | CAFS1000B |
| Place of Origin: | WUXI |
| MOQ: | Please contact us for details |
| Price: | Offline conversation or face-to-face discussion |
| Payment Terms: | L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments |
| Supply Ability: | 999 |
| Delivery Time: | 3-7 work days |
| repetitiveness: | <0.5% |
| Output eggplant type: | Frequency output ranges from 2.05 to 11.69,nalog outputs of 1-5V selectable |
| Flow range: | 10-800Kg/h customizable |
| precision: | ±2.0% F.S |
| Company Info. |
| Wuxi Consensic Electronic Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Functional items | CAFS1000B Output Eggplant Type Frequency Output Ranges From 2.05 To 11.69 Nalog Outputs Of 1-5V Selectable | ||
| performance parameter | unit | remarks | |
| Flow range | 10-800 | Kg/h | customizable |
| service voltage | 14 | VDC | |
| accuracy | ±2.0 | % FS | |
| repetitiveness | <0.5 | % | |
| response time | 20 | ms | selectable |
| maximum pressure | 0.3 | MPa | |
Output eggplant type | Frequency output ranges from 2.05 to 11.69 Analog outputs of 1-5 | KHz V | selectable |
| temperature | -40~125 | ℃ | |
| levels of protection | IP40 | ||
| Calibrate oneself type | Air, and the 20℃,101.325kPa | ||
| The overall material | ABS | ||
| Volume Flow (Kg/h) | Output Frequency (Hz) |
|---|---|
| 0 | 2076.8 |
| 10 | 2181.366 |
| 15 | 2271.137 |
| 75 | 3009.908 |
| 160 | 3726.415 |
| 310 | 4932.51 |
| 640 | 8615.288 |
| 800 | 10450 |
|
