Desktop Barcode Reader 1D 2D Omnidirectional QR Code Scanning Platform

Categories Desktop Barcode Scanner
Brand Name: DYscan
Model Number: DP8210
Certification: CE ROHS FCC IEC
Place of Origin: China
MOQ: 1pcs
Price: negotiable
Payment Terms: T/T, Western Union,PAYPAL
Supply Ability: 100000pcs/month
Delivery Time: 5-7days
Packaging Details: 54*34*34CM/30pcs /Carton
Scan Type: CMOS
Resolution: ≥5mil/0.127mm(PCS90%,Code 39)
Decoding speed: 640*480
Scan Mode: Continuous ,Auto sense
Symbologies: 1D 2D
Dimension: L86.7mm * W96.7mm * H143.6mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Desktop Barcode Reader 1D 2D Omnidirectional QR Code Scanning Platform

Desktop Barcode Reader 1D 2D Omnidirectional QR Code Scanning Platform Bar Code Scanner

Feature

☆ High-performance MCU to easily identify the mainstream 1d or 2d barcode.

☆ Read barcodes above 4mil to meet the need of daily scanning.

☆ 2d imaging technology, support paper, printing, plastic, screen barcode.



Performance

Scan TypeCMOS
Light SourceAiming: 617 nm LED ; illumination:6500K LED
CPU32-bit
Resolution640*480
Start time4s
Resolution≥5mil/0.127mm(PCS90%,Code 39)
Decoding speed80cm/s
Depth of field

0-380mm

Scan Mode

Continuous ,Auto sense

Indicator

buzzer , LED

Scan angleRoll360°, Pitch±45°, Skew±32°
Print Contrast Signal≥25%
Ambient LightDark environment, indoor natural light
Symbologies

1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 32, Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5(Straight 2 of 5),Standard 2 of 5(IATA 2 of 5),Codabar(NW-7),MSI,GS1 Databar(Omnidirectional, Limited, Expanded),China Post, Tepepen, GS1 Composite etc.

2D: QR Code, Micro QR Code, Data Matrix,PDF417, Micro PDF 417, MaxiCode, Aztec,HanXin Code, Chinese ID Card OCR, etc.



Physical Parameter

Weight

270g(without cable)

Dimension

L86.7mm * W96.7mm * H143.6mm

Communication Mode

USB(USB-KBW,USB-COM),RS232

Interface TypeUSB, RS232
Power Supply

DC 5V@470mA(work)



Environmental

Operating temperature-20℃ to 55℃
Storage temperature-20℃ to 60℃
Humidity5% to 95%(non-condensing)
Drop Height1.2m
Transport Vibration Test10H@125RPM



Detail Image





















Quality Desktop Barcode Reader 1D 2D Omnidirectional QR Code Scanning Platform for sale
