Name: Auto Fuses 3070A 6568mV Voltage Drop Tin plated Copper Terminal
Brand: Julun
Price: 1 USD

Home > Fuses >

Auto Fuses 30-70A, 65-68mV Voltage Drop, Tin plated Copper Terminal

Categories	Automotive Blade Fuses
MOQ:	100 / Negotiable
Price:	Negotiable
Payment Terms:	L/C, D/P, T/T,
Supply Ability:	10000/Piece/Weekly
Delivery Time:	7~10 Working days
Packaging Details:	Standard carton
Brand Name:	Julun
Certification:	CE/UL/VDE/KC/ROHS
Model Number:	CP
Place of Origin:	China
Interrupting Rating:	40A~400A
Voltage Rating:	12V-24V
Operating Temperature Range:	-40˚C to + 125˚C
Housing:	Transparent Nylon Composite
Terminal:	Tin plated Copper
Mounting Torque M5:	4.5 Nm +/- 1Nm
Complies with:	ISO 8820-5
Application:	Automotive, Marine, Industrial
Brand:	OEM/ODM
Breaking Capacity:	6000A
Color:	Red, Blue, Yellow, Green, White, Black
Current Rating:	2A-30A
Material:	Copper, Zinc Alloy
Operating Temperature:	-40℃~+125℃
Package:	Carton Box, Plastic Bag
Product Name:	Automotive Blade Fuses
Size:	Standard Size
Warranty:	1 Year

Contact Now

Add to Cart

Company Info.

JULUN (H.K)CO.,LTD (DONGGUAN JULUN ELECTRONICS CO.,LTD)

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Auto Fuses 30-70A, 65-68mV Voltage Drop, Tin plated Copper Terminal

Abf-199-1. g See Larger Imageabf-199-1. g Bolt In Auto Blade Automotive Fuses (FBELE)

Features

Standard Auto fuse

Auto fuses in Gold or Nickel plated

Fuse types:MAXI/AGU/ANL/MINI-ANL fuses are optional

We will send you sample for your quality testing before your order

AMP# are optional for different types,20-300AMP

Interrupting Rating: 1000A @ 58 VDC
Voltage Rating: 32/48/58 VDC
Operating Temperature Range: -40˚C to + 125˚C
Housing: Transparent Nylon Composite
Terminal: Tin plated Copper
Mounting Torque M5: 4.5 Nm +/- 1Nm
Complies with: ISO 8820-5
UL 248 Special Purpose Fuses

Time-Current Characteristics

% of Rating	Opening Time Min / Max (s)
% of Rating	30-125A	150-200A
75	– / –	360,000 s / –
100	360,000 s / –	– / –
110	14,400 s / –	– / –
150	90 s / 3,600 s	– / –
200	3 s / 100 s	1 s / 15 s
300	0.3 s / 3 s	– / –
350	– / –	0.3 s / 5 s

Ratings

Part Number	Current Rating	Typ. Voltage Drop	Cold Resistance	I2t
FKYANS/ANM-030	30 A	65 mV	2.06 mΩ	4200
FKYANS/ANM-040	40 A	65 mV	1.398 mΩ	10000
FKYANS/ANM-050	50 A	65 mV	1.025 mΩ	13000
FKYANS/ANM-060	60 A	68 mV	0.865 mΩ	21700
FKYANS/ANM-070	70 A	70 mV	0.72 mΩ	24000
FKYANS/ANM-080	80 A	58 mV	0.541 mΩ	24600
FKYANS/ANM-100	100 A	60 mV	0.457 mΩ	51300
FKYANS/ANM-125	125 A	71 mV	0.394 mΩ	73200
FKYANS/ANM-150	150 A	77 mV	0.323 mΩ	81900
FKYANS/ANM-175	175 A	77 mV	0.285 mΩ	100000
FKYANS/ANM-200	200 A	77 mV	0.261 mΩ	125000

Dimensions

FAQ

Q: What can i do if i got a broken product form A-TEAM FUSE INC?
A: First of all please tell us as soon as possible after we will send a new one to you immediately

but please send the broken product to us .you don't have to worry about the carriage charge we will

pay for that.
Q;Are we a importer or manufacturer?
A;We are a manufacturer
Q:Why you have to choose us
A:High quality assurance. The most competitive price and fast shipping

Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most

competitive price per as your requirements. And we have many types for you to choose.

P.S.:If you can't find any products to meet your requirements. welcome to send us the details

drawings so that we can provide us our professional & best service to you.
