High Efficiency Horizontal Deep Well Submersible Pump 380 / 440 / 660 Voltage

submersible deep well pump of 6",8",10",12" with large flow rate and high head, high efficiency

Product Application

submersible deep well pump is my company developed vertical single suction multi-stage submersible pump.Pump and motor is an organic whole repeatedly, into the water, this series of pump is the main tool, deep well water use in urban and rural areas, industrial and mining enterprises and agricultural irrigation water.

Work Condition
1. Power: 380v/440v/660v, 3ph, 50hz/60hz
2. Medium: clear water

- not above 25ºC (95ºC for the type of heat-resisting)
- shot contents (mass ratio) not avove 0.01%
- PH 5-10
- content of hydrogen sulfide not above1.5mg/L
- chloride ion not above 400 mg/L
3. the water pump must be fully filled with clean water before installation.
4. the installation depth must not exceed the fixed lift 20%; the inwall of the well should be smooth and straight.

Model signification:
200QJ32-91/7
200------Base No.
QJ--------Submersible Pump
32--------Pump Flow
91--------Pump Head
7----------Impellers

Shijiazhuang Aier Machinery Co., Ltd. is a large-scale professional manufacturer of slurry pumps, gravel pumps, dredge pumps, sewage pumps and clean water pumps in China.

All products are mainly supplied to environmental protection, wastewater treatment, urban water supply and drainage, mine, metallurgy, coal, petrochemical, building material, thermal power FGD, river dredging, tailing disposal and other fields. The products are selling well in China and sold far to Germany, U.S., Canada, Australia, Russia, Ukraine, Kazakhstan, Brasil, Chile, Argentina, Bolivia, Malaysia, Indonesia, India, Poland, South Africa, Tanzania, etc.

Our firm has strong technical force and is specially engaged in the research of abrasion resistant materials of slurry pumps, sewage pumps and water pumps and the development of new products. The materials include high chrome white iron, duplex stainless steel, stainless steel, ductile iron, rubber, etc.

We use CFD, CAD method for product design and process design based absorbing experience of world leading pump companies. We integrate molding, smelting, casting, heat treatment, machining and chemical analysis, and have professional engineering and technical personnel.

Our company started to build our new factory in 2013 and finished in Spring of 2014. The new factory is located in Lincheng Xingtai Hebei, covering 67,000 m² and of annual design annual casting capacity 3,000 tons. In the new factory, we can produce different parts from small to huge. Casting & machining orders are welcome as well.
