Brand Name: | SHARP |
Model Number: | LQ31E05 |
Certification: | ISO9001 |
Place of Origin: | KOREA |
MOQ: | 1 |
Payment Terms: | Western Union, T/T, MoneyGram, T/T |
Supply Ability: | 500PCS/DAY |
Delivery Time: | 1-3WORK DAY |
Packaging Details: | Antistatic bag, Bubble Bag, Foam Box and Carton Box. |
Resolution: | 383×234 |
Panel Size: | 3.0 inch |
Panel Type: | a-Si TFT-LCD , LCM |
Active Area: | 61.7×44.5 mm |
Outline: | 102.2×78.5×5.9 mm |
Display Colors: | Full color |
Response Time: | 30/50 (Typ.)(Tr/Td) |
Viewing Angle: | 45/45/30/10 (Min.)(CR≥10) (L/R/U/D) |
Company Info. |
N&S ELECTRONIC CO., LIMITED |
View Contact Details |
Product List |
LQ31E05 3.0 inch Sharp LCD Panel with 61.7×44.5 mm Active Area
LQ31E05 Specification
Panel Size : | 3.0 inch | |
Dot Resolution : | 383×234 | |
Pixel Configuration : | RGB Delta | |
Pixel Density : | 89 PPI | |
Aspect Ratio : | 7:5 (H:V) | |
Form Factor : | Flat Rectangle Display | |
Pixel Pitch : | 0.161×0.190 mm (H×V) | |
Weight : | 17±5g | |
Active Area : | 61.7×44.5 mm (H×V) | |
Outline Dimension : | 102.2×78.5 mm (H×V) | |
Outline Depth : | 5.9 (Max.) mm | |
Holes & Brackets : | Face mounting holes (4-Φ5) on left, right bezel | |
Landscape or Portrait : | Landscape type | |
Touch Panel : | Without | |
Display Mode : | TN, Normally White, Transmissive | |
Display Color : | Full color () | |
Response Time : | 30/50 (Typ.)(Tr/Td) | |
| 45/45/30/10 (Min.)(CR≥10) (L/R/U/D) | |
| 11% (Min.)(with Polarizer) | |
Sunlight Readable : | N |
Quality Control:
Make sure No damage, No Scratches, No dusty, No light leakage.
Make sure all functions are 100% tested ok
Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Antistatic bag
2. Layers of cartons
3. Foam Box
4. Carton Box.
Below are our other LCD panels stock for your easy reference:
Panel Model | Brand | Size | Resolution |
LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
LQ156D1JX02 | SHARP | 15.6" | 3840×2160 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
LQ31E05 Picture
![]() |
