IEEE 802.3af Gigabit POE Power Over Ethernet Splitter 5v - 12V DC Output For IP Camera

Categories Power Over Ethernet Splitter
Brand Name: E-link
Model Number: LNK-FLQ1000D
Certification: CE/FCC/Rohs
Place of Origin: Guangdong, China
MOQ: 1
Price: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000pcs Per Month
Delivery Time: 4-6 days
Packaging Details: Standard export package
Transmission rate: 10/100/1000Mbps
PD detection: Yes
POE input: IEEE802.3af
Output: DC 5v 2A
Mounting Options: DIN-Rail / Wall-mount
Dimensions: 95 x 70 x 30 mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

IEEE 802.3af Gigabit POE Power Over Ethernet Splitter 5v - 12V DC Output For IP Camera

IEEE 802.3af Gigabit PoE Splitter with 5-12V DC output

Model: LNK-FLQ1000D

Overview


The Splitter LNK-FLQ Series is a economical and practical, with high performance and high reliability, and electric equipment based on the IEEE 802.3af PoE remote, can through the cable transmission of power and data signal separation. The LNK-FLQ Series splits the 48VDC over the RJ45 Ethernet cable into 5V/7.5V9V/12V power output, with the use of power supply equipment, can be flexible to expand the home network, office network, without the need to limit the layout of the power line.


Features

  • The IEEE 802.3af Ethernet standard support
  • Support 10/100M or 10/100/1000M data transmission
  • The PD receiving end 36V-57V support various voltage transfer, the use of UPS DC power users
  • Selectable power output: it can provide 5V, 7.5V, 9V, 12V voltage, to adapt to a variety of small network devices
  • High quality design, effectively ensure the stability of the equipment reliability
  • Short circuit protection
  • LED indicators for power input indication
  • Plug-and-Play, requires no configuration

Technical Parameters


POE separator product specifications
Product modelLNK-FLQLNK-FLQ100LNK-FLQ1000
POE Agreement802.3af Standard802.3atStandard
Port speed10/100M10/100/1000M
Input voltageDC48V/0.3ADC48V/0.6A
Output voltage5V/2A;7.5V/1.5A 9V/1.1A;12V/1A5V/4.5A;7.5V/2.5A,9V/2.3A;12V/2A
POE Pin1/2(+),3/6( - )4/5(+),7/8( - )Compatible
LED IndicatorDC power supply is green
TemperatureWorking temperature: -10 ~ 45 °C
Humidity10~90%(non condensing)
Size72 (long) x 55 (wide) x 31 (high) mm
Weight250g
Safety & EmissionCE,FCC

POE splitter A.jpg
