H71 Carbon Steel Wafer Type Non Return Valve Lift One Way 300LB 8 Inch

H71 Carbon Steel Wafer Type Non Return Valve Lift One Way 300LB 8 Inch

Specifications

Design According to API 594
Face to face according to API594
Pressure & Temperature Rating according to ASME B16.34
Test & inspection According to API 598
Materials: CF8M (SS316), CF8 (SS304), DIN4.4408/4.4308 Available
Working Pressure: 150LB~300LB
Suitable Temp.: -196ºC~550ºC( Different temp. for different material)
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid

Application

The H71W stainless steel clamp-on lift check valve uses a new type of material with corrosion-resistant stainless steel. It can be installed on the pipeline at any position to prevent the medium from flowing backwards. The boiler feed water system is back up. The connection method is to use the flanges at both ends of the original pipeline to be put into operation. Its various indicators are superior to any of the currently available upper return valves. The use of the check valve H71W-150LB/300LB is widely used in water supply and drainage, fire protection, construction, HVAC, industrial systems. Any medium such as water, gas, oil, acid, lye, hydrogen, ammonia, special fire protection pipes can be used. For example, it can be installed at the outlet of the pump to avoid water hammer, water hammer and destructive impact, to prevent backflow and protect equipment, and to have better energy saving effect.

Feature

Why choose us?

Wenzhou Xidelong Valve Co.,Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of valve , with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching the Middle East, Europe,Asia.

Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. Besides, we have received ISO9001 and CE.

Package&Delivery

Packing Details: We choose suitable wood cases according to different valves and arrange skilled workers to pack in case of bruise. Long term cooperated forwarder will book space, clear customs and transport for us without delay. There are three ways for transportation, by sea, by air and by train. We will arrange transportation according to customers' needs.

Delivery Details: according to the order, 7~60days

FAQ

Q: Are you trading company or manufacturer ?

A: We are a factory.

Q: How long is your delivery time?

A: According to the order,7~60days.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

Xidelong Brief Introduction

Xidelong is a professional manufacturer in valve automation, integrating with research and development, manufacturing, sales and after-sales services of valve and accessories over 12 years.

The factory of Xidelong valve is located in Longwan (Zhejiang, China), covering an area of 25,000 square meters, of which square meter is for office work whereas 24,000 square meters is for production (including the assembly area, testing area and warehouse area). Moreover, the factory is only 9 miles to Wenzhou Airport, greatly facilitating for the visitor of our international customers and partners.

Boasting of excellent technical strength, design and experience in Gate, Ball, Butterfly and Bellow valves manufacturing, the company has a quality management system as required by ISO9001-2008.

Xidelong Valve have been working to find reliable sales agents or distributors.

Xidelong Manufactory

Established in 2007, Xidelong Valve is a preferred supplier of industrial valves for major Chinese manufacturers.The factory of Xidelong valve is located in longwan (Zhejiang, China).

Xidelong Business

Valve: Ball Valve, Butterfly Valve, Gate Valve, Globe Valve,  Check Valve, Sight Glass

Material:  ● Steinless Steel: CF8, CF8M, CF3, CF3M, Duplex Stainless Steel

Material:  ● Casting Steel: WCB, WC6, WC9, A105, LCB

Accessories: Pneumatic Actuators, Electric Actuators, Worm Gear, Manual Override, Limit Switch, Solenoid Valve

Standard: JB/GB, ANSI/API, JIS, DIN

Xidelong Production

We are equipped with CNC lathes, automatic machining centers, automatic MIG seal welding and automatic hard facing facility to reduce human error. Today equipment and technology along with a qualified training to our employees produce valves as required by international market.

Xidelong Testing

All our production is tested in accordance to the standard required.

We analyze the raw material at first. Any piece is verified in order to respect the required tolerance. Each valve must exceed the pressure test before it has been judged ready for delivery.
