550 Ton Plastic Crates Manufacturing Machines , Industrial Injection Molding Machine

550T Automatic Plastic Plate Moulding Machines

Specification:

			GS558V
			A	B	C	D
INJECTION UNIT	Screw Diameter	mm	80	85	90	100
	Screw L/D Ratio	L/D	21.2	20	18	17.6
	Shot Size(Theoretical)	cm3	2362	2667	2990	3691
	Injection Weight	g	2150	2427	2721	3359
	Injection Rate	g/s	403	455	510	629
	Plasticizing Capacity	g/s	79	95	110	141
	Injection Pressure	Mpa	184	163	146	118
	Screw Speed	rpm	0-120
CLAMPING UNIT	Clamp Tonnage	KN	5580
	Toggle Stroke	mm	900
	Space Between Tie Bars	mm	840*830
	Max.Mould Height	mm	850
	Min.Mould Height	mm	320
	Ejector Stroke	mm	220
	Ejector Tonnage	KN	158
	Ejector Number	piece	17
OTHERS	Max.Pump Pressure	Mpa	16
	Pump motor Power	KW	(V)55/(HS)23+23
	Heater Power	KW	44.3
	Machine Dimension(LWH)	m	8.812.272.45
	Machine Weight	t	22
	Hopper Capacity	Kg	100
	Oil Tank Capacity	L	640

Machine Characteristic:

1. Strengthen locking structure

Optimized special locking system to reach efficient and fast production

2. Centralized lubrication, reliable protection

Configuring rational centralized lubrication, providing more professional, better lubrication to make machine more cleaner.

3. Professional templates optimized design

Template by advanced finite element analysis software to optimize design, high rigidity, high strength, to meet the rapid impact conditions demand.

4. Powerful, friendly control system

Adopts professional controller and friendly interface, easy and fast operation, with good reliability.

5. New type screw driving system

Spline connection for screw and oil motor, smooth and reliable transmission, big transfer torque, easy disassembly.

6. Excellent injection performance

Double cylinder injection, entire floor-guided, reliable and stable.

7. Superior clamping system

Adopts optimized connection rod structure, faster and smoother operation.

8. New frame structure

Simple and generous appearance, machine body force reasonable and stronger.

9. Professional plasticizing system

Suitable for different types of plastic raw material with professional plasticizing and heating system, good plasticizing performance.

10High efficient powerful servo system optional

Power system adopts high pressure gear box and servo motor, rotary encoder, pressure transducer and servo amplifier to get system closed-loop control.

FAQ:

Q1: Are you a trading company or a manufactory?

A1: We are a manufactory, we supply the factory price with good quality, welcome to visit !

Q2: What’s your guarantee or the warranty of the quality if we buy your machines?

A2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.

Q3: When can I get my machine after I paid?

A3: The delivet time is based on the exact machine you confirmed.

Q4: How can I install my machine when it arrives?

A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.

Q5: How about the spare parts?

A5: After we deal down all the things , we will offer you a spare parts list for your reference.

Product Tags:


*From:	Your email address is incorrect!
*To:	shanghai Guangsu Manufacture Co.ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Large Injection Molding Machine
Brand Name:	GS
Model Number:	GS558V
Place of Origin:	Shanghai, China (Mainland)
Certification:	ISO9001
Price:	Negotiable
MOQ:	1 Set/Sets
Type:	Preform Injection
capacity:	save much more energy
Power(W):	44.3kW
After-sales Service Provided:	Overseas third-party support available
Injection Weight:	3359g
Injection Rate:	629g/s
Clamping Force:	5580KN
Opening Stroke:	900mm
