Cross Linked IXLPE Fire Retardant Insulation Foam Prevents Condensation
| FIRE RETARDANT IXLPE FOAM | |
| Foam Density | Standard 33.3±3kg/m3 Various options available 28 – 300 Kg/m3 |
| Thickness | 1-8mm |
| Width | 1-1.55meter |
| Length | 50meter per roll |
| Adhesive | Self strong adhesive are availble |
| Fire retardant class | HF-1 |
| Fire-resistance | Available in Class A,Class B |
| Characteristics | · Closed cell structure · Long lasting insulation material · Excellent thermal insulation · Acoustic noise reduction · Constant energy saving · Flame retardant protection · Prevent condensation · Easy installation · Lightweight |
Application
House ware, building industry,
Automotive industry,
Acoustics, aircraft industry,
Electronics
Packaging,
Sport and leisure industry
Advantages
1) Waterproof,clean, light, flexible,non-absorbent surface.
2) Recyclable, environmentally friendly
3) Easily install, cut, stapled, nailed or glued into place.
4) Effective in extreme temperatures both hot and cold.
5) Safe to handle with no special clothing or breathing Equipment.
6) Easy to cut and install, without the protective clothing or
respirators during installment.
7) Does not support the growth of fungus or mold.
8) Vapor and radon retarder.
9) Not affected by moisture or humidity.
Specifications
CYG TEFA CO.,LTD | ||||||||||||
| IXPE foam specification | ||||||||||||
| Test Item | Index | Standards | ||||||||||
| 3Times | 5Times | 8Times | 10Times | 15Times | 20Times | 25Times | 30Times | 35Times | 40Times | |||
| Density (kg/m3) | 300±40 | 200±30 | 125±15 | 100±10 | 66.7±8 | 50±6 | 40±4 | 33.3±3 | 28.6±3 | 26±3 | GB/T6343 | |
| Shore Hardnes (°) | Thick＞3mm | 65～75 | 60～70 | 50～60 | 45～50 | 35～45 | 30～35 | 25～30 | 18～25 | 13～18 | 13～18 | GB/T2411 |
| Thick≤3mm | 55～65 | 45～55 | 35～45 | 25～35 | 20～25 | 15～20 | ||||||
| Tensile Stength (Mpa) | T | ≥1.4 | ≥1.3 | ≥0.9 | ≥0.7 | ≥0.5 | ≥0.4 | ≥0.3 | ≥0.2 | ≥0.15 | ≥0.15 | GB/T6344 |
| L | ≥1.6 | ≥1.5 | ≥1.0 | ≥0.8 | ≥0.6 | ≥0.5 | ≥0.4 | ≥0.25 | ≥0.2 | ≥0.2 | ||
| Elongation (%) | T | ≥210 | ≥200 | ≥150 | ≥130 | ≥130 | ≥130 | ≥110 | ≥110 | ≥100 | ≥100 | GB/T6344 |
| L | ≥230 | ≥220 | ≥170 | ≥150 | ≥150 | ≥150 | ≥120 | ≥120 | ≥110 | ≥110 | ||
| Tearing Stength (KN/m) | T | ≥10 | ≥9 | ≥8 | ≥6 | ≥4 | ≥2.5 | ≥2 | ≥1.5 | ≥1.3 | ≥1.3 | GB/T10808 |
| L | ≥10 | ≥9 | ≥8 | ≥6 | ≥4 | ≥2.5 | ≥2 | ≥1.2 | ≥1.2 | ≥1.2 | ||
| Compressed Distortions (%)23℃±2℃,22h | ≤2 | ≤2 | ≤3 | ≤5 | ≤7 | ≤8 | ≤9 | ≤10 | ≤11 | ≤11 | GB/T6669 | |
| Size change rate (%)70±2℃,22h | T | ≤-4 | ≤-4 | ≤-4 | ≤-4 | ≤-4 | ≤-6 | ≤-6 | ≤-6 | ≤-6 | ≤-6 | GB/T8811 |
| L | ≤-6 | ≤-6 | ≤-6 | ≤-6 | ≤-6 | ≤-8 | ≤-8 | ≤-8 | ≤-8 | ≤-8 | ||
| Water Absorbtion (g/cm2)23℃±2℃,24h | ≤0.02 | ≤0.02 | ≤0.02 | ≤0.03 | ≤0.03 | ≤0.04 | ≤0.04 | ≤0.05 | ≤0.05 | ≤0.05 | GB/T1034 | |
| Thermal Conductivity (w/m.k) | ≤0.095 | ≤0.095 | ≤0.084 | ≤0.073 | ≤0.065 | ≤0.055 | ≤0.049 | ≤0.045 | ≤0.040 | ≤0.040 | GB/T10297 | |
About CYG
Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc.
Years Of Experience
17 years of production experience.
Scale Of Factory
17 production lines : 9 production lines in Shenzhen and 8 production lines in Huzhou .
Production Capacity
Annual 6000 tons
Why choose us
1.The biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China
2.The most complete cross-linked polyethylene foam products.
3.Certificate: UL, ISO, SGS, Rohs, Reach , CE
4.OEM service
5.High quality,
6.Defective goods after sale service.
Cooperative Partner
iPhone, Samsung, Gree, Haier, TCL, Nike, Flextronics, General Motors, BYD, PPL, etc.
CYG TEFA offers the best solution for polyethylene foam production,
We supply PE foam in rolls, the length of each roll can be customized to meet customer’s requirement.
The PE foam product can also be provided on the sheet as a request.
Here support foam die- Cutting,Lamination Adhesive ,Sheeting, Perforating & Skiving.
All the service are focused on quality of products and satisfied our customer.
|
