Multiple Pressure Air Flow Sensor Switch Hvac 125/250VAC Easy Connection

Differential Pressure Air Flow Switch for HVAC system

This switch is a SPDT type airflow one and can be used for detecting on -off status of the airflow to ensure normal operation of system. This product can be used for any detection conditions with various filtrated airflow rates, such as environmental engineering, central air-conditioner, business office building and factory etc.

In an air treatment, it can adopt the control switch to setup acoustic-optical alarm device for cut-out or chained action of switching off circuit of heater and electric valve to avoid harmful effect on equipment and users resulting from overheat of vent-pipe, freezing of coil pipe and others when cut-off happens.

Characteristics:

Adoption of shell with water drop infiltration prevention function made of stainless steel and engineering plastics.

Firm switching contact in the shell with dust prevention function.

Easy connection of lead.

Easy setting and regulating of function positions.

Wiring

When the flow rate rises, the contact(R)-(Y) will be closed

Range of airflow: 2~8m/sec.

Temperature range: 82℃

Electric parameters:

Rated current of switch contact: 5A~10A

Rated voltage: 125/250VAC

Dimension
