Speed Reducer Gearbox With Huge Rolling Torque for Roughing Stand of Hot Plate Mill

Speed reducer Gearbox hot plate mill finishing house roughing stand

Description

SEEC’s main driving gearboxes for hot plate rolling are applied to production lines of hot plate rolling and provide power drive for rough rolling zones and finishing rolling zones of production lines of continuous hot plate rolling and continuous plate casting and rolling.

SEEC's main driving gearbox for hot plate rolling includes a main reducer with reduction ratio and a gear housing for power allocation. The power and torque of the main motor can be transmitted to the two rollers of the hot plate after the main reducer and the gear housing are serially connected and driven, rolling the mill via speed reduction and distribution.

The production line of hot plate rolling has large rolling reduction and large roll force, so that the driving system must provide huge rolling torque and has harsh requirements for reliability and stabilization of design and manufacture of the gearbox in the main driving system.

SEEC's main driving gearbox for hot plate rolling can completely meet drive requirements.

Technical Data

Rated power: maximum 12,000 kW
Stage: 1 or 2
Speed ratio: 1-10
Torque:maximum 4,200 kN.m

Advantages

Optimized flank modification
High housing rigidity
Large torque transmission
Weight reduction by carburizing and quenching wielding gear hard flank

Application

Continuous hot rolling, continuous plate casting and rolling.

Typical Case

Beijing Sino Steel Engineering & Equipment Co., Ltd. is concentrating on developing of ferrous & non-ferrous making and Rolling technology, mainly.

As one of the most experienced Chinese suppliers of complete line and components for steel and non-ferrous industries, Beijing Sino Steel Engineering & Equipment Co., Ltd. is engaged in design, manufacturing, engineering and service activities on word-wide basis.

Overseas Partners (Office):

India, Indonesia, Malaysia, Thailand, Korea, Turkey, UAE, Qatar, Iran, Saudi Arabia, Kuwait, Germany, France, Canada, USA, Brazil, Etc.

MAIN SCOPE SUPPLY:

EPS Project Line:

EAF, LF, Continuous Casting Machine, Preheating Furnace, Hot Rolling Mill Line, Cold Rolling Line, Centrifugal Casting Line, Slitting Line,Cut-to-length Line, Cleaning Line, Pickling Line, Coating line, Levelling line, Billet grinding line ETC.

Components & Parts:

Mill stand, Coiler, Uncoiler, Gearbox, Leveller, Copper Mould Tube, Copper Mould Plate, Water Jacket, Water Cooled Cable, Forged Rolls, Casting Rolls, Roll Shell, Roll Core,Bearing, Universal Shaft, Lathe, ETC.

​
