High Brightness Led Public Display 3mm Led Screen 1R1G1B / SMD2121 Black Lamp

Categories Indoor LED Display
Brand Name: Vegoo
Model Number: VG-FD 3
Certification: CE/ROHS/FCC
Place of Origin: China
MOQ: 1 Sq.m
Supply Ability: 3000 Sq.m / month
Delivery Time: 15 working days
Packaging Details: Plywood case / Flight case / Carton box
product name: P3 Indoor Full color LED Display
Pixel Pitch: 3mm
Pixel Configuration: 1R1G1B/SMD2121 Black lamp
Density: 111,111pixel/m2
Moduel Size(L×W)mm: 192mm×192mm
Brightness: 800cd/㎡
Contrast: 1000:1
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Brightness Led Public Display 3mm Led Screen 1R1G1B / SMD2121 Black Lamp


P3 Indoor Full color LED Display 1R1G1B/SMD2121 Black lamp


Description:


1) High refresh rate , high brightness and high contrast which make the screen without any delay and smear phenomenon under direct sunlight.

2) Energy saving:low electric current,high-bright lamps

3) The brightness can be adjustable to meet the need of changing environment

4) Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for wide horizontal

5) Environment protection, antistatic, dust-proof, good heat dissipation, cost-effective .

6) Error detection and monitoring:it can monitor the inner temperature,voltage,cooling fans etc and error detection automatically.

7) High reliability: using distributed scanning technology and module design technology that make higher reliability and stability.

8) Steady and reliable system:with strong anti-interference ability and long service life that can continually work for over 24 hours, and it’s easy to operate the system.

9) Favorable effect: using dot to dot calibration technology makes the image clearer and the layering stronger

10) Convenient installation and maintenance of display modules


Remote Control
Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique
Self-inspection, communication test, power test, temperature monitoring (Be customized)

P3 Indoor Full color LED Display Specification


Product NameSpecification
Pixel Pitch3mm
Pixel Configuration1R1G1B/SMD2121 Black lamp
Density111,111pixel/m2
Moduel Size(L×W)mm192mm×192mm
Cabinet Size(L×W×H)mm576mm×576mm×90mm
Module Resolution64×64
Cabinet Resolution192×192
Driving Method1/32 Scan
Driving ICMBI5124 or ICN 2038S
Brightness800cd/㎡
Contrast1000:1
Brightness AdjustmentAuto and Manual
Power ConsumptionMax Power:<800W
Average power: <200W
Module Weight0.25kg
Color Temperature9500K—11500K
Horizontal Viewing Angle140º
Vertical Viewing Angle140º
Signal Processing10 or 14bit
Grey Processing1024×1024×1024
16834×16834×16834
Control Distancecable100m,Multimode500m,Single mode 2km
Frame Frequency65 Hz
Refresh Rate>1920Hz
Control ModeSynchronous/Asynchronous
The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF>50000 hours
Life Span100,000 Hours
Operating TemperatureWorking : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
Power SupplyAC 110-220V
Protectiondustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

Applications:


Stage Background

Airport Station

Television Relay



Our service


1. Your inquiry related to our products or price will be replied in 2hrs

2. OEM customized products

3. 2 years warranty

4. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

5.Free technician training..

6.Top quality+Reasonable price+Responsible After Service=Successful & Win
