COB Character FSTN Graphic LCD Display Module 16x2 International Standard

COB Character FSTN 16x2 lcd display screen

COB Character FSTN 16x2 lcd display screen International standard export package
Delivery Time
Sample LT:Around 7 days; Mass LT:4-5 weeks

1. LCD mode : FSTN/ Positive/Transflective
2. Viewing direction : 12 o’clock
3. Driving scheme : 1/16 Duty cycle, 1/4 Bias

4. Low power operation : Power supply voltage range (V DD ): 3.3V
5. Operating temperature : -20℃~70℃
6. Storage temperature : -30℃~80℃

3-1. Module size : 85.9mm(L)*30.8mm(W) *5.8mm(T)
3-2. Viewing area :80.1mm(L)*18mm(W)

3-3. Dot pitch : 0.83mm(L)*0.83mm(W)
3-4. Dot size : 0.78mm(L)*0.78mm(W)

    Shenzhen OK Smart-Lcm Photoelectric Co.,Ltd is a high-tech company who run display equipment research, produce and sales, with most advanced technology and strong strength. Shenzhen OK Smart-LCM Photoelectric Co.,Ltd owns their independent producing center-Jiangxi Huaersheng Technology, serving large-scale enterprise within China and outside China.
    We set several department, including vehicle dept.Intelligent software dept, mono LCD dept, TFT LCD dept and OLED dept. We also have Beijing, Shenzhen, Shanghai sales office, and Beijing, Shenzhen R&D center, factories in Jiangxi Wanzai.Our LCD, LCD module, TFT LCD, PMOLED, AMOLED and flexible LCD spreads around the world. Our producing capacity can reach over 2 billion RMB a year.
    We own many high-tech producing equipment, including incision,cleaning, grinding and patch, CFOG bonding, automatic glue spray, full plying-up, backlight assemble, product test. With several years development, We owns many Panasonic full-automatic equipment, and cooperate with all those panel factories. We offer LCD display technique to many Chinese vehicle factories like BAIC group, SAIC group, form our own full industry chain. We have cooperation with those famous enterprise inside or outside China, like Skyworth, Bosch China, SouGou, Foxconn.
    So far, our products cover industrial control digital readout, vehicledisplay, business display, electronic end, medical equipment, intelligent home.
     OK Smart fellows will keep creative mind and keep technique update. We will stand on the front of the era of science and technology with our newer/better/stronger technique. We will serve every customer with high quality and advanced technology.
