Three Colors Synthetic Rubber Band Extrusion Machine , Plastic bands Making Machine

Categories Plastic Extrusion Machine
Brand Name: YAOAN
Model Number: AF-65
Certification: CE
Place of Origin: CHINA
MOQ: 1
Packaging Details: WOODEN BOX
Delivery Time: 30-90 DAYS
Payment Terms: TT,LC
Supply Ability: 100 SETS PER MONTH
Material: TPU, TPR ,TPV, SBS
Screw: 65MM
LD: 28:1
Motor: Dongguan
Inverter: ABB
Warranty: 1 year
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Three Colors Synthetic Rubber Band Extrusion Machine , Plastic bands Making Machine

Three Colors Synthetic Rubber Band Extrusion Machine,Plastic bands Making Machine


Customers according to production needs, monochrome or color out of the host structure, with themold, cooling sink, traction machine, cutting machine, and air delivery systems and other components, products widely used in toys, decorations, and gift packaging purposes.


Φ50 Three Color Rubber Band (elastic) extrusion production line configurations and quotation:


Φ55 single screw extruder: one set

Screw diameter: 55mm

Screw L/D: 28:1

Screw style: special (suitable raw material: TPR,TPU,SBS)

The screw and the barrels are all made of high quality nitrided steel-38CrMoAIA,and are nitration austerely according to NATIONAL STANDARD, nitration hardness: screw≧740HV; harrels≧940HV. Nitration depth:0.3-0.7mm;screw:0.4-0.6mm, barrel:0.6-0.7mm;fragility is 2 grades.

Gear box: one set

Drive motor: 15kw (Chinese famous brand)

Control style: frequency conversion (Delta brand)

Assistant machine Φ30×2(set)

Screw diameter: 30mm

Screw L/D: 25:1

Screw structure: special

Gearbox (one set)

Control power: 3kw×2

Thermostat zones: 5 zones ( adopts Winpark temperature controller)

Radiator zones: 3 zones

Electrical control box: one set

Co-extrusion mould: one set


4m stainless steel cooling water tank: one set

Water tank frame: one set


1M belt Haul off machine: one set

Haul off control power: 1.5kw

Haul off control style: frequency inverter


Cutting machine: one set (25 blades)

Cutting unit control power: 3.0kw

Cutting unit control type: frequency conversion

Haul off roller drive motor:0.75kw

Material collection unit: one set

Size: 600mm*400mm*400mm
