220 Ton PP / PE Plastic Injection Molding Machine with Saving Energy Servo Motor

PP/PE Plastic Injection Molding Machine with Saving Energy Servo Motor HM220

Control part:

1.It adopts imported advanced computer for plastic injection machine , with large screen, high definition crystal display and human-computer interface in various languages, such as Arabic, English, Spanish, Farsi, etc. Through CPU independent control and individual treatment, it has raised the running speed of the control system and alarming of successive oil temperature , thus warrants the operating speed of the machine.

Closed–loop temperature control system ensures the accuracy and reliability of the barrel temperature. Equiped with the functions of cold –proof boot, alarming and parameter memory for the molding, as well as password protection. The injection and switch are controlled by imported locating ruler.

Injection part:

1.The excellent chrome , molybdenum and aluminum alloy screw and barrel have undergone the nitrilizing process, applicable to various plastic materials.

2.The injection cylinder(258T advanced) is parallel or balance for both sides of the barrel, so as to ensure the non-deviation of the nozzle, good sealing and non-leadage. It is equipped with double guide pillar supporting system which can inject under multifarious pressure at various speeds. It also uses one-stop hydraulic pre-injection device.

Hydraulic part:

It adopts the imported top quality hydraulic components, proportional control for pressure and flow.

Moulding-adjustment part:

Mold is adjusted by gear controlled by oil motor , the mold can be adjusted automatically in accordance with the setting pressure , which is both convenient and reliable.

Ningbo Qiming Machinery Manufacturing Co.Ltd. was founded in 1998,it is a modern specialized enterprise in production of extrusion blowing molding machinery and injection molding machinery. Located in a world famous manufacturing center--Ningbo High Tech Economic And Technological Development Zone.

Vaino international limited is the sub marketing company especially do the marketing ,offer service for injection molding machine , blow molding machine with accessories along with the solutions for packing,labeling ....
Our customer covers more than 30 countries and areas all over the world.
With the effort of the whole company, our team become very professional in technical supporting ,pre-service and aftersales service.
We guarantee 48hrs service and fast response and we believe that Promise and responsibility is the most important thing in every business section.

Top-quality,professional services,honest in trustworthiness.we are willing to carry out policy of superiority supported each others,to own the resoure mutually.Two-winners for development,and as always to create the brilliantness of future with the customers hand in hand!
