A Water and Impact Resistant Touchpad / Industrial Computer touch mouse
Product Feature
• Accurate orientation& Higher stability
• Lighter touch and non-fatigue for a long time using
• Lower power consumption
• Waterproof, dustproof, wearable in a seal condition
• Top metal panel mounting solution.
• PS/2 or USB connector is available.
• Customized layout is available.
MECHANICAL DATA
• Touchpad: 62 x 46 mm;
• Front Mounting Panel: 88mm x 67 mm (front panel),
• It is compatible to WINDOWS98/ME/2000/2003/XP/Vista/ Linux, Unix, Mac OSX
• Front panel & Keys: super quality SUS304 Brushed stainless steel
• Back Metal Cover: Rear side integrated electronics protected by a metal cover
• N.W.:0.2 KGs
TECHNICAL SPECIFICATION
• X/Y position sensing resolution: 1000 points/inch (40 points/mm)
• X/Y position reporting: Relative
• Power supply 5V DC+ 10%,
• Work current 4.0 mA (normal)
• Tracking speed: Maximum 1,016 m/sec
• Protection level: IP65 (front panel)
• Static Release: 15 KV (front panel)
• EMC Standard: EN55022(B)
ENVIRONMENTAL ADAPTABILITY
• Operating temperature:-10°C to +55°C
• Storage temperature: -20°C to +65°C
• Operating RH: 10-95%
• Atmospheric pressure: 60-106Kpa.
RELIABILITY
• Compliant RoHS , CE and FCC
• Protection Level: IP65(front panel)
• Touchpad Lifespan >10 million actuations
• MTBF >5,0000H
• MTTR <30min
Detailed Product Description
| Mechanical | Dimension: | (W x H): 88 x 67 mm (Front panel) |
| Front panel | aluminum | |
| Touchpad thickness | 1.3 mm PCB thickness inclusive of mylar layer | |
| Interface | PS2 or USB are available | |
| Packing | 9pcs/EPE/inner box, 30boxes/ctn | |
|
