2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever

BEYOND Balanced Audio fiber optic transmitter and recever provide uncompressed high quality real time transmission for Stereo or Mono Bi-directional or Single-direction audio signals over one single mode or multimode optic fiber.

Features:

No adjustments; pure digital processing and transmission

24 bit/96 kHz sampling; maximum audio level +24 dBu 20 Hz to 20 kHz frequency response

Line level, balanced or unbalanced audio operation Indicator

LEDs monitor audio signals and power

Wide range power supply allows operation from low voltage AC and DC sources

Card version fills one slot in 6000A card cage

System consists of transmitter and receiver unit; card or box version. Each end, plus power supply, must be purchased separately

Specifications

Audio
Input/output Impedance	600ohm(balance)
Max input/output voltage	3.0Vp-p
Frequency Response	10 Hz～29kHz @±3dB
SNR	> 70dB
Connector	Standard terminal lead

Electrical & Mechanical
Input Power Requirements:	DC 5V@2A
Power Adapter:	AC 90V~240V
Power Consumption:	< 3W
Stand-Alone Dimensions:	183mm × 154mm × 54mm
Shipping Weight:	(include Transmitter & Receiver ) 2.0kg

Environmental
Operating Temperature:	-20°C ~ +75°C
Storage Temperature:	-40°C ~ +85°C
Relative Humidity:	0% ~ 95% (non-condensing)
MTBF:	>100,000 hours
