Capillary Tube Mobile Induction Welding Equipment for Air Conditioning Distributors

Categories Induction Brazing Machine
Brand Name: OURUIDA
Model Number: DSP-40KVA
Certification: CE ,ISO, ROHS,GSG
Place of Origin: CHINA
MOQ: 1set
Price: Negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000SETS /Month
Delivery Time: 3-7days
Packaging Details: Export Wooden box Packaging
Name: Mobile InductionWelding machine
Machine Structure: Water cooled system inside
Operation: Very easy to operate
Handheld transformers: 3M-8M
Features: Easy to moving , Highly efficient, Saving Energy
Test Videos: We can provide More videos for you confirm
Test reports: Provided
Power supply: 25KW-50KW
Company Info.
OURUIDA CO.,LTD
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Capillary Tube Mobile Induction Welding Equipment for Air Conditioning Distributors

Mobile Induction Capillary Tube Welding Equipment for Air Conditioning Distributors:

Mobile induction Welding Machine Features:



  Easy to move: Hand-held brazing equipment can achieve induction brazing for complex and inaccessible workpieces or workshop locations, with small size, easy movement and simple operation.

  Highly controllable: The controllability and precise heat transfer of induction heating minimises the risk of overheating, thus avoiding damage to the heated workpiece and reducing the degree of attrition.

  Precise operation: high frequency, stable heating output and vibration-free working heating ensure accurate welding positions. Capillary metals with a minimum diameter of 0.1 mm can be welded and the inductor can be customised to suit the different shapes of the workpiece.

  Easy to operate: no need to transport or store batches of workpieces near the brazing equipment when brazing, ideal for in-line brazing.

  Reduced costs: The efficient and precise heating process ensures acceptable welding rates, minimising scrap, rework and energy consumption.

  Efficient working environment: induction heating is quiet and comfortable and does not cause the surrounding environment to heat up.


Technical Parameters:

Product Name Portable Digital heating machine
Control Mode Digital
Operating Mode Manual Mode,Automatic Mode,Temperature control mode
Number of Heating Current 5-32 segments
Number of Workpiece Parameters stored 10group
Work Status Display Time,Current,Frequency,Current Time Curve
Alarm Interface Lack of water,over current,over voltage,lack of phase,over current of the drive board, abnormal load,out of control,etc
Model Number DSP-40KVA
Output Power 25kw
Main Extension Cable 3m,5m,8M
Input Voltage 340V-480V
Input Frequency 50/60Hz
Power Factor 0.93
Minimum circuit breaker 3P-32A
Maximum Water Temp of Inlet Water <40℃
Cooling Water Flow 12.5-17L/min
Chassis size 940MM*760*MM1180MM

Application ofMobile induction Welding Equipment :

It is mainly used to join two metals of the same or different materials together by heating to a certain temperature to melt the solder, and the specific applications are as follows:

● Welding of various hardware tools: diamond tools, abrasives, drilling tools, alloy saw blades, carbide turning tools, milling tools, reamers, planing tools, woodworking drills, etc;

● Welding of various hardware machinery parts: hardware sanitary products, refrigeration copper parts, lighting parts, precision mould parts, hardware handles, egg beaters, silver welding and copper welding of alloy steel and steel, steel and copper, copper and copper, etc. of the same or different metals;
