| Categories | Fiber Optic POE Switch |
|---|---|
| Brand Name: | Olycom |
| Model Number: | OM011008-PSE-FE |
| Certification: | CE RoHS FCC ISO9001 |
| Place of Origin: | Shenzhen, China |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, PayPal |
| Supply Ability: | 2500pcs/month |
| Delivery Time: | 4~8 working days |
| Packaging Details: | 1pc in a box, 1.05kg gross weight |
| Product name: | 8-Port 10/100M PoE Switch |
| Feature: | Unmanaged, smart POE |
| POE budget: | 120W |
| POE protocol: | IEEE802.3af, IEEE802.3at |
| Size: | 220*140*45mm |
| Weight: | 1.05kg |
| Company Info. |
| Shenzhen Olycom Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Key Features of 8-port POE switch
Specification of 250m active POE switch
| Power | Power Adapter Voltage | AC 110V-240V | |
| Consumption | 120W | ||
| Network Port | PoE Ethernet Port | 1~8 Port : 10/ 100Mbps |
| Ethernet port | Uplink Port : 10/ 100/1000Mbps | ||
| Fiber Port | Uplink Port : 1000M SFP | ||
| Transmission Distance | 1~8 Port : | ||
| Uplink Port : 0 ~ 100m | |||
| SFP: depend on the SFP transceiver (20km-120km) | |||
| Transmission Medium | Cat5/5e/6 standard network cable | ||
| Network Standard | IEEE802.3/802.3u, | |
| Switching Capacity | 2.0Gbps | ||
| Packet Buffer Memory | 1Mbits | ||
| Throughput | 1.488Mpps | ||
| MAC Table | 1K | ||
| Packet Forwarding rate | 10Mbps:14880pps/port | ||
| Power Over Ethernet | PoE Standard | IEEE 802.3af/at | |
| PoE Power Supply | 12 45 + ,36 78- , 8 core power supply | ||
| PoE Power | af=15.4W,at=30W for each port | ||
| RJ45 port | Port Function | Power priority mechanism, | |
| LED Indicator | LED Indicator | LINK/ACT.100Mbps; | |
| Environmental | Working temperature | 0C~55C | |
| Relative Humidity | 20~95% | ||
| Storage temperature | -20C~70C | ||
| Mechanical | Dimension (L ×W × H) | 220mm*140mm*45mm | |
| Color | Black | ||
| Weight | 1.05kg | ||
FAQ
1 Q: What is your lead time?
A:It usually takes 2~4 working days to produce and then will send
goods.
2 Q: How will you send my goods?
A: We will send the goods by DHL, TNT, UPS or FEDEX, please check
the delivery details by the tracking number.
3 Q:Tell me something about your packing.
A: It is neutral packing. If you have your own packing box, we
support it.
4 Q: What is warranty time?
A: A year for commercial products and 3 years for industrial
products. Technical support will be offered free.
| Products Category | Warranty Period |
| Fiber media converter | 1 year |
| Optical Video Converter | 1 year |
| Fiber Switch | 1 year |
| Ethernet Extender | 1 year |
| Fiber Modem | 1 year |
| PDH Multiplexer | 1 year |
| Industrial switch | 3 years |
|
