| Categories | Dual Mode ONU |
|---|---|
| Brand Name: | V-solution |
| Model Number: | V2801SD-1GPD |
| Place of Origin: | Guangdong, China |
| MOQ: | 1 pcs |
| Price: | Negotiable |
| Payment Terms: | Negotiable |
| Supply Ability: | 1000 pcs/day |
| Delivery Time: | 3-5 days |
| Packaging Details: | Carton |
| Proudct: | GPON ONU with Reverse PoE |
| Type: | FTTx Solutions, epon/gpon onu |
| Special functions: | DHCP/PPPOE/Static IP |
| L3: | IPv4,IPv6 and IPv4/IPv6 dual stack |
| PoE: | DC +12 ~ +24V |
| Material: | ABS Plastic |
V2801SD-1GPD Dual Mode ONU Most Popular 1GE Secure With Reverse PoE
Product Description
V2801SD-1GPD GPON 1GE Safe ONU, It can also be applied to a wide temperature environment, and also has a powerful firewall function.The box is based on the mature Gigabit GPONtechnology, highly reliable and easy to maintain, with guaranteed QOS for different service. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.
Interface Description
| Port Type | Function |
| PON | Connect PON port with internet by SC/UPC type, single mode optical fiber cable. |
| LAN | Connect device with ethernet port by RJ-45 cat5 cable. Optional support PD(reverse POE) function. |
| RST | Press down reset button and keep1-5seconds to make the device restart and recover from the factory default settings. |
| DC12V | Connect with power adapter. |
Key Features
| Software Key Feature | |
| EPON/GPON mode | Dual mode , Can access EPON/GPON OLTs. |
| Software mode | Bridging mode and Routing mode. |
| Abnormal protection | Detecting Rogue ONU, Hardware Dying Gasp. |
| Firewall | DDOS, Filtering Based on ACL/MAC/URL. |
Indicators
| LED | Mark | Color | Status | Description |
| system | SYS | Green | On | Device is powered on and starting. |
| Blink | Device is running normally. | |||
| Off | Device is powered off. | |||
| Optical signal state | REG | Yellow | Blink | Device is not registered to the PON system. |
| Green | Blink | Device is being registered. | ||
| Green | On | Device is registered to the PON system. | ||
| Interface | LINK/ACT | Green | On | Port is connected properly . |
| Off | Port connection exception or not connected. | |||
| Blink | Port is sending or/and receiving data. |
|
