BWS5000E Digital Output Dual Axis Inclinometer Tiltmeter Accuracy 0.001°

BWS5000E Series High-Stability Digital Output Dual Axis Inclinometer Temperature drift 0.0003°/℃ Cross axis error 0.001°

Introduction

BWS5000E is a dual-axis high-precision, high-stability inclinometer with MEMS technology and digital output, with a surge (impact) immunity of IEC 61000-4-5 level IV launched by Bewis Sensing, with a measuring range of ± 15°, the highest accuracy is 0.001°, and the temperature drift is ±0.0003°/℃.

Performance index

Application

Tunnel and dam monitoring

Tower tilt monitoring

Surveying and Mapping Instruments

Wind turbine tower monitoring

FAQ

Q1: Accuracy definition of products

A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.

Q2: How to select suitable model?

A: Users should check the following points:

a. Single or dual axis?

b. Common protocol, Modbus or CAN?

c. Dynamic or static Application scenarios?

d. Horizontal or vertical installation?

Q3: How to purchase?

A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.

Q4: How long is the warranty period?

A: One year.

Q5: Can analog quantity change the range?

A: User-defined settings can be made on the Bewis host computer with RS232-USB through the reserved RS232 wire harness.
