| Categories | TFT Resistive Touch Screen |
|---|---|
| Brand Name: | HongYu |
| Model Number: | HY60640982560 |
| Certification: | CE.FCC.ROHS,CCC |
| Place of Origin: | China |
| MOQ: | 5 pcs |
| Price: | negotiation |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10Kpcs/month |
| Delivery Time: | 7-15 working days |
| Packaging Details: | Standard export package |
| Size: | 6.6inch |
| Resolution: | 4098(Horizontal)*2560(Vertical) |
| LCM (W x H x D) (mm): | 154.36(W)x99.1(H)x1.22(D)mm |
| Active Area(mm): | 143.43(W)x189.6(H)mm |
| Brightness: | 1000nits |
| Interface Type: | 40pin 2port LVDS(Adjustable) |
| Viewing Angle: | 85/85/85/85(Typ.)(CR≥10) |
6.6 Inch 4098x2560 4k Monochrome LCD Display Module Without Backlight
6.6 inch 4098x2560 monochrome tft 4K LCD Display Module 4098x2560
Product Description
| No. | Item | Spec |
| 1 | LCD size | 6.6 inch |
| 2 | Model Name | HY60640982560 |
| 3 | Resolution | 4098x2560(4K LCD panel) |
| 4 | Active area | 143.43(W)x189.6(H)mm |
| 5 | Outline Size | 154.36(W)x99.1(H)x1.22(D)mm |
| 6 | Backlight | Without backlight,original open cell |
| 7 | Viewing direction | Free |
| 8 | Pixel Pitch | 0.035(W)x0.035(H)mm |
| 9 | UV transmission | 6~7% |
| 10 | Signal Interface | 50pins MIPI |
| 11 | Environment | Operating Temp.: 0~ 70 °C Storage Temp.: -10 ~ 80 °C |
| 12 | Contrast Ratio(405nm UV) | 500:1 |
| 13 | Aplication | 3D printer |
6.6 inch 4098x2560 monochrome tft 4K LCD Display Module 4098x2560This product is our standard product, used in Android tablet computers, video players, catering equipment, CNC control and other display panels. All products can provide touch panels, PCBA solutions and complete machine solutions. Products can be made according to customer requirements Customization; if you have any questions about the product, please contaThis product is our standard product, used in Android tablet computers, video players, catering equipment, CNC control and other display panels. All products can provide touch panels, PCBA solutions and complete machine solutions. Products can be made according to customer requirements Customization; if you have any questions about the product, please contact us as soon as possible, we will serve you wholeheartedly, thank you!ct us as soon as possible, we will serve you wholeheartedly, thank you!
|
