PCC PCL Pallet Transfer Conveyor With Cam Direction Conversion

Shelly Niu, wechat/whatsapp: 86-13671843635

Conveyors -Pallet Flow series with cam direction conversion machine

Product Description:

• The Pallet Flow series is based on the original cam direction converter, and uses four conveyors and other accessories to make the incoming and outgoing of pallet flow smoothly.
• The Pallet Flow series can be divided into PCC(Pallet Chain Flow conveyor), PCL(Pallet Chain Liveroller Flow conveyor), PAC(Pallet Friction Accuma Flow conveyor), PZP(Pallet Zeropressure Accuma Flow conveyor). The classic model of pallet flow is Pallet Chain Flow conveyor, which can make heavy objects move stably and reliably during pallet transportation. Pallet Chain Liveroller Flow conveyor can be used when pallet chain flow conveyor cannot be used for conveying.

• Pallet Chain Live Roller Flow
  model	PCL500	PCL1000
  Can be carrying amount	500kg/m	1000kg/m
  Roller dimensions (od) thickness	Φ60.5*12.3mm	Φ76.3*t3.8mm
  The shaft	Φ 12 mm long	Φ 17 mm long
  bearing	Low noise type	Low noise type
  Sprocket teeth (chain * number of teeth)	NO.50*8 A single	NO.60*9 A single
  Fuselage width (outer axis ~ outer fuselage) MW	w*125mm	w+150m'm
  Roller width W	600·1200	800`1500mm
  Actual width dimensions of roller	W-4mm	w-3mm
  Roller pitch P	75.10 0.150mm	630`1200
  Fuselage length L (multiple tooth spacing)	1500`12000mm	1500 (p200Under the condition of1600)·1200
  Fuselage high H(FL 'roller feeding surface)	570~12000mm	630~1200mm(Adjust the+-50mm)
  The motor capacity	0.4.0.75.1.5kw	0.4.0.75.1.5kw
  Move to speed	5`15m/min(1m/min each)	5~15m/min(1m/min each)
  The power supply	three 220v



• ---

Pengya was founded in 2005, the specialty is engaged in the research and development, the virtual design of intelligent automation equipment system integration planning, technology integration, professional manufacturing, quality, and professional project management services, in line with "integrity, dedication, pragmatic, innovation" business philosophy, on the basis of intelligent automation control software technology, combined with domestic and foreign advanced technology, through independent innovation development of products.

Along with the adjustment of industrial structure at present, our company also keep pace with The Times, according to the demand of the market, the application of the technology transformation of accumulated products: industrial interconnection, visualization, enterprise resources, MES manufacturing execution management software, logistics, factory automation conveying system, electronic materials, PCB bonding systems, lifting equipment, robot handling system, coating system, environmental energy equipment, engineering plastics.

Since then, various combination of intelligent robot handling system and automatic warehouse have been successively developed, which has made great contribution to the development of manufacturing industry. At present, the company is providing software, mechanical force logistics system and automation system of factory equipment in a wide range of fields such as electronics, automobile, medicine, food, publishing, textile, environment and transportation led by communication sales and other circulation industries. In the future, we believe there will be a growing need to improve working conditions and quality through industrial Internet + intelligent automation. Reducing management and production costs has become an urgent issue faced by all industries. Providing efficient industrial Internet + intelligent logistics system and autocratic factory equipment is the obligatory social mission of Pengya Intelligent.

Position

High-end product and intelligent equipment system integration service provider

Concept

Integrity, dedication, pragmatism, innovation、win-win

Mission

Internationalization, branding, specialization

The target

Achievement of customers, achievement of brands, achievement of employees
