320x256 / 30μm Cooled Gas Leakage Detector Camera with 23mm Lens for Petrochemical Industry

GAS330 gas leak detection camera integrates 320x256 / 30µm MCT cooled MWIR infrared detector and covers mid wavelength from 3.2 to 3.5μm.

It is a cooled infrared camera module that can detect the leaks of dozens of volatile organic compounds (VOCs). VOCs are human-made chemicals that are used and produced in the manufacture of paints, pharmaceuticals, and refrigerants, some of which may have short- and long-term adverse health effects.

By using this thermal module, inspectors can quickly detect harmful gas leakage, which plays a very important role in safe production, efficiency improvement and cost saving.

- Resolution: 320x256

- Pixel Pitch: 30µm

- NETD≤15mK, High Sensitivity

- Spectral Response: 3.2µm±0.1µm~3.5µm±0.1µm

- Wavelength Customizable Based on Different Requirements

- Integrate with DVP/CameraLink Interface Easily

The GAS330 gas leak detection thermal imaging camera is used for visiualizing the invisible VOCs (volatile organic compounds) and detecting gas leakage such as: Methane, Ethane, Propane, Butane, Pentane, Hexane, Heptane, Octane, Ethylene, Propylene, Isoprene, Methanol, Ethanol, Butanone, Benzene, Toluene, Xylene, Ethylbenzene etc.

1.What are the advantages of uncooled infrared detectors?

Uncooled infrared focal plane detector does not need cooled device, it can work at room temperature and has the advantages of fast start, low power consumption, small size, light weight, long life, low cost and so on.

2.What are the key considerations on an infrared detector / thermal module for your application?

---The detector resolution

---The pixel size

---The NETD

---The image quality

---The lens options

---The power consumption

---The size and weight

---The mechanical & electrical interface

---The budget
