BLE Nordic Nrf52840 Module 6dBm Bluetooth Ble Module BLE52840SA-B

Categories	Bluetooth Module
Brand Name:	Cansec Wireless
Model Number:	BLE52840SA-B
Place of Origin:	Beijing
MOQ:	100
Price:	USD 5.14$ per piece
Payment Terms:	T/T
Supply Ability:	2000000 pieces per year
Delivery Time:	3~6 weeks
Packaging Details:	Box for 1000 pieces Package size: 403420 cm Gross weight: 5.000 kg
size:	18.633.42.8mm
TX Power:	6dBm
RX sensitivity:	-103dBm
TX current:	36mA
RX current:	4.6mA
Standby current:	1.5uA
Antenna type:	Chip Antenna
Chipset:	nrf52840

Contact Now

Add to Cart

Company Info.

Beijing JiaAn Electronics Technology Co., Ltd.,

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

BLE Nordic Nrf52840 Module 6dBm Bluetooth Ble Module BLE52840SA-B

BLE52840SA-B BLE module with Nordic nrf52840 chipset

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.7	3.3	5.5	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	1.5	-	uA
	Receive mode	-	4.6	-	mA
	Transmit Mode (@6dBm)	-	36	-	mA
TX Power (For Carrier)		-	-	6	dBm
RX Sensitivity (For Lora Modulation)		-	-	-103	dBm
Distance		180			m

BLE52840SA-B BLE module with Nordic nrf52840 chipset

1. The BLE52840 module is designed based on nRF528402. The nRF52840 is fully multi-protocol capable with full protocol concurrency. It has protocol support for Bluetooth 5, Bluetooth mesh, Thread,
Zigbee, 802.15.4, ANT and 2.4 GHz proprietary stacks.
3. The nRF52840 is built around the 32-bit ARM® Cortex™-M4 CPU with
floating point unit running at 64 MHz.
4. It has NFC-A Tag for use in simplified pairing and payment solutions.
5. The ARM TrustZone® CryptoCell cryptographic unit is included
on-chip and brings an extensive range of cryptographic options that
execute highly efficiently independent of the CPU.
6. It has numerous digital peripherals and interfaces such as high speed SPI and QSPI for interfacing to
external flash and displays, PDM and I2S for digital microphones
and audio, and a full speed USB device for data transfer and power
supply for battery recharging.
7. Exceptionally low energy consumption is achieved using a sophisticated on-chip adaptive
power management system.

FAQQ1: Are you a factory or trade company?
A1: We are a professional factory with 25 years experience.
Q2: Can you accept OEM/ODM?
A2: Sure, we have rich OEM&ODM experience.
Q3: Do you have quality assurance?
A3; Each of our products has undergone quality testing and has two
years of free after-sales service.
