| Categories | WDM Module |
|---|---|
| Brand Name: | GAPHO |
| Model Number: | FWDM |
| Place of Origin: | China |
| MOQ: | 50 |
| Price: | negotiate |
| Payment Terms: | T/T, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 |
| Delivery Time: | 7-10 day |
| Packaging Details: | Carton,pearl cotton,bubble bag,plastic bag |
| Package Dimension (mm): | 80 x 60 x 10 |
| Storage Temperature (°C): | -40 ~ +85 |
| Operating Temperature (°C): | 0 ~ +70 |
| Power Handling (mW): | 300 |
| Return Loss (dB): | ≥ 45 |
| Directivity (dB): | ≥50 |
| Express Channel Isolation (dB): | > 25 |
| Insertion Loss Temperature Sensitivity(dB/°C ): | < 0.003 |
100Ghz Optical Add/drop Module(OADM) 1530.33 ~ 1560.61 (21~ 59 ITU grid)A 100Ghz Optical Adddrop Module(OADM).docx
Features
Application
specifications
Type Parameter | 1ch | 2ch | |||
| Channel Wavelength (nm) | 1530.33 ~ 1560.61 (21~ 59 ITU grid) | ||||
| Center Wavelength Accuracy (nm) | ± 0.05 | ||||
| Minimum Channel Spacing (GHz) | 100 | ||||
| Channel Passband (@-0.5dB bandwidth)(nm) | > 0.22 | ||||
Insertion Loss (dB) | Add / Drop Ch1 | ≤1.2 | ≤1.2 | ||
| Add / Drop Ch 2 | - | ≤1.5 | |||
| Express Ch. | ≤1.0 | ≤1.4 | |||
| Add / Drop Channel Ripple (dB) | ≤0.3 | ||||
Isolation (dB) | Demux | Adjacent Ch. | ≥ 25 | ||
| Non-adjacent Ch. | ≥40 | ||||
Mux | Adjacent Ch. | N/A | |||
| Non-adjacent Ch. | N/A | ||||
| Express Channel Isolation (dB) | > 25 | ||||
| Insertion Loss Temperature Sensitivity(dB/°C ) | < 0.003 | ||||
| Wavelength Temperature Shifting (nm/ C ) | < 0.002 | ||||
| Polarization Dependent Loss (dB) | < 0.10 | ||||
| Polarization Mode Dispersion (ps) | < 0.1 | ||||
| Directivity (dB) | ≥50 | ||||
| Return Loss (dB) | ≥ 45 | ||||
| Power Handling (mW) | 300 | ||||
| Operating Temperature (°C) | 0 ~ +70 | ||||
| Storage Temperature (°C) | -40 ~ +85 | ||||
| Package Dimension (mm) | 80 x 60 x 10 | ||||
Ordering information
| OADM | Spacing | Channel Type | ITU Channel | Pigtail Type | Fiber Type | Lengt h | Connector |
| 1=100Ghz | 1=1ch 2=2ch | 21=21ch 22=22ch …… 60=60ch | 900=900um loose tube 2000=2mm loose tube 3000=3mm loose tube | 1=SMF-28e | 1= 1m X=Specify | NE=None FA=FC/APC FC=FC/UPC SA=SC/APC SC=SC/UPC LC=LC/UPC LA=LC/APC |
company prolife
We are specialized in providing solutions for optical cable,
packaging solutions for optical devices, and manufacturing of other
electronic equipment parts. Our products are widely used in optical
communication, electronics, medical care, oil pipeline, audio
industrial control, radio, instrumentation and other industries.We
have a good design and production team to provide customers with
high-quality, reliable and efficient products.
In the process of cooperation, our innovation and service awareness
are well received by our customers.
The company specializes in the production of optical communication
equipment, optical devices, optical jumpers, distribution boxes,
distribution frame.Our company
1.Machinery department: provide precision machinery processing,
sheet metal parts processing, plastic injection molding processing,
processing and manufacturing supporting various parts.
2. Optical communication department: provide customized processing
of optical devices such as optical jumper, optical module, optical
switch, wave divider, attenuator adapter, coupler, optical
splitter, circulator, isolator, collimator, optical amplifier, etc.
According to the customer's requirement.
We can provide packing according to customer's requirement, quantity, weight and volume.
We can provide customized products for customers. We only need to provide requirements, samples, specifications, drawings, etc.
FAQ
Q:Can you design and customize production according to my requirements
A:Yes, you can tell us your requirements and ideas, we can design drawings, or provide samples, 2D floor plans or 3D drawings (support proe, solidwork, core, Auto CAD, DXF, DWG, step file formats).
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:What certificate we have?
A: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
Q: What is your delivery date?
A: The delivery date is approximately 3-5days, depending on the order quantity.
.
|
