SMK9601 Intelligent deviation correction control system WEB GUIDING
Based on the introduction of advanced European and American technology, the intelligent deviation correction control system has been optimized and upgraded a lot. The product integrates the core team's R & D and application experience in the deviation correction industry for more than 10 years. The comprehensive performance of the product is leading, and some functions are the first in the industry!
Dominant features
No manual intervention is needed, and the best accuracy can be achieved under any working condition;
Real time display of operation status and data, simple operation, simple and beautiful interface;
It is applicable to edge inspection, line inspection, centering, following, edge staggering and other correction types and rich parameter settings.
The product can realize up to 32 online operations and centralized control;
A variety of automatic location technology of detection points can reduce material waste and labor.
Intelligent control system
Unilateral deviation correction system
Alignment and correction system
Double layer automatic following system
Wide centering / edge detection intelligent switching system
Wide centering and deviation correction system
Customized systems for lithium battery, sanitary materials and other industries
Sensors
Edge detection ultrasonic sensor
Edge detection infrared sensor
Line inspection CCD sensor
High precision wide range edge detection sensor
Sensor automatic moving edge finding system
Sensor automatic movement centering system
Servo impeller
Linear pusher for unwinding / rewinding (40 kgf - 1000 kgf)
Pusher for guiding frame in process (10 kgf - 150 kgf)
Deviation correction device
GF-S (50 mm - 650 mm roll width):
GF-M middle wide guide and stop frame
GF-W large amplitude guide frame
GF-SF end fulcrum guide frame
Featured functions
■ Integrated design: professional industrial design, integration of various components
■ Powerful performance: rich built-in functions, various communication and control functions
■ System stability: built in various protection circuits, and stable operation under complex working conditions
■ High precision of deviation correction: the high-precision design of each component realizes the high-precision deviation correction of the whole system
■ Convenient operation: touch screen interactive interface, clear at a glance, one key operation
■ Exquisite appearance: compact structure, small volume, beautiful and exquisite
■ Easy installation: it can be installed at any angle, and can be integrated or separated
Electrical linkage:Electric + pneumatic control + light button
Fine appearance:Strip and cylinder built-in design, fine processing of aluminum alloy
Customized on demand:The manual splicing table can be customized, and other parts can also be customized. It can output pressing signals, limit position alarm signals, PLC external control and RS485 communication optional.
The P series includes a receiving table split machine
| Main technical parameters | ||||||
| GF-S/ Model | 150 | 200 | 250 | 300 | 350 | 400 |
| Rolling diameter | 50 | 50 | 50 | 50 | 50 | 50 |
| Capacity Width | 150 | 200 | 250 | 300 | 300 | 400 |
| Max Rolling diameter | 200 | 250 | 250 | 300 | 350 | 400 |
| B deviation correction angle | ≤±5 | |||||
D series small split machine
Featured functions:
Exquisite appearance and effective height saving
Correctable extremely narrow width materials
All sizes can be customized on demand
GF-M/W medium wide guide frame
Featured functions:
Design on demand: medium and wide deviation correction can be designed and produced according to customers' needs
Fine processing: high standard processing requirements, ensure the balance of the guide and the fine surface treatment
Strong structure: the frame is designed according to the tension value of the customer's material, and sufficient strength safety factor is considered
Flexible installation: it can meet any installation mode of customers
F-SF end fulcrum guide frame
|
