Practical Off Grid Hybrid Solar Power Inverter With 100A MPPT Controller

Categories M Power Inverter
Brand Name: SolarverTech
Model Number: MPS-V 3500W-PLUS
Place of Origin: Zhejiang, China
MOQ: 100
Price: negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 200000
Delivery Time: samples in 5 working day
Packaging Details: as requirement
Product name: 3500w off grid hybrid pure sine wave solar inverter with inbuilt 100A mppt controller for solar energy systems
Type: DC/AC inverter
weight: 11~12kgs, 11kgs;12kgs
warranty: 1 year
OEM: accept
Display: LCD
controller: 100A MPPT controller
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Practical Off Grid Hybrid Solar Power Inverter With 100A MPPT Controller

3500w off grid hybrid pure sine wave solar inverter with inbuilt 100A mppt controller for solar energy systems


Product Description

Pure sine wave solar inverter

Output power factor 1.0

WIFI & GPRS available for IOS and android

Inverter running without battery

Buit-in 100A MPPT solar charger

High PV input voltage range(120-500VDC)

Buit-in anti-dusk kit for harsh environment

Smart battery charge design to optimize battery life



Specification


Model No.MPS-V-3500-24VMPS-V-5500-48
Rated power3500VA /3500W5500VA /5500W
Inputvoltage
selectable voltage range170-280VAC(For Personal Computers) 90-280Vac(For Home Appliances)
Frequency range50Hz/60Hz(Auto Sensing)
OutputAC voltage regulation (Batt.mode)230VAC ±5%
Surge power7000VA11000VA
Efficiency (peak)PV to INV.97%
Efficiency (peak)Battery to INV.94%
transfer time10 ms(For Personal Computers);20ms(For Home Appliances)
waveformPure sine wave
Battery&AC chargerbattery voltage24VDC48VDC
floating charge voltage27VDC54VDC
overcharge protection33VDC63VDC
maximum charge current80A80A
Solar chargerMAX PV array power5000W6000W
MPPT range@ operating voltage120~450VDC
maximum PV array open circuit voltage500VDC
maximum charging current100A
maximum efficiency98%
PhysicalDimension, D*W*H(mm)100x300x400
Net weight (kgs)1112
Communication interfaceUSB/RS232
operating Environmenthumidity5% to 95% Relative Humidity(Non-condensing)
operating temperature0℃-55℃
storage temperature-15℃-60℃

Function


Company Profile

Jiaxing Solarway New Energy Company is a Sino-Germany Joint venture,has strong technological strength, exquisite production technology, as well as advanced and innovative production processes and equipments. All of our products have obtained the certificate of conformity from the National Institute of Measuring and Testing Technology, Science and technology constitute a primary productive force. With over 30 national patents for invention, our company takes the lead in passing the ISO9001 Quality Management System certification, CE,Rhos,E mark UL certification.
