Low Frequency Pure Sine Wave Solar Inverter AC Voltage VAR Regulation

Categories Solar Controller Inverter
Brand Name: J-ENERGIZE
Model Number: JET-SL 5000
Place of Origin: XIAN, CHINA
MOQ: 1 Unit
Payment Terms: L/C, T/T, Negotiable
Delivery Time: Negotiable
Packaging Details: Carton
Application: Home Appliance,All electrical equipments,solar system
Output waveform: pure sinewave
Batteries Voltage: 24V/48V /96V DC
Rated Power: 5000W
Efficiency: 90%
Protection: Over Voltage,short-circuit,over-load, over-temp
AC Voltage Regulation: 230Vac±3% (Battery mode)
AC charge current: 0~35A adjustable 15A max @96Vdc
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Low Frequency Pure Sine Wave Solar Inverter AC Voltage VAR Regulation

SL5000 Low Frequency Pure Sine Wave Solar Inverter AC Voltage VAR Regulation

JET-SL Series Pure Sine Wave Inverter


Product features

  • Smart control via digital CPU, smart charging
  • Pure sine wave inverter
  • Wide range for the AC input voltage
  • AVR function built-in, continue to output the stabilize voltage.
  • Overload and short circuit protection
  • High as the efficiency, low expend in vain

Specification

ModelSL 1000SL 2000SL 3000SL 4000SL 5000SL 6000
Rated Power1kw2kw3kw4kw5kw6kw
Input
Voltage170~265VAC
Frequency45~65Hz
Output
AC Voltage Regulation230Vac±3% (Battery mode)
Frequency±0.5Hz (Battery mode)
Efficiency>90%
WaveformPure sine wave
Others
Battery formOptional battery type(optional)
Battery rated voltage12V/24V/48V DC24V/48V /96V DC
AC charge current0~35A(optional) 15A max @96Vdc
ProtectionOver load, short circuit, battery voltage high and voltage low,AC voltage high and voltage low
Conversion modeOnline interactive
Communication interfaceRS-485
Overload capacity110%-120% of the output was maintained for 30 seconds, then the output turned to bypass, and more than 160% maintained the 300ms.
Relative Humidity< 90% Non-condensate
Operating Temperature-0℃ ~ 60℃
Storage Temperature-20℃ ~ 75℃
Overall Dimensions475*300*185 (mm)650*300*185 (mm)
Net Weight12.7 (kgs)15.5 (kgs)17 (kgs)22.9 (kgs)25.5 (kgs)29.5 (kgs)

1. Pre-service

-- 24 Hours online service for your consult.

-- Help choose right model, and a series of service, person, advise.


2. Middle service

-- Give you best offer

-- Provide discount for many sets order

-- Do customer's request:

-- Choose payment term you convenient.

-- Promptly production and delivery, inform you in time.

-- Can provide invoice value as you like to decrease your tax.


3. After sale service

-- 1-year warranty service and all life maintenance.

-- Technical engineer are available for oversea training.

-- Free change for some parts.

-- Remote control technical consult.

-- Free installation DVD.

-- Maintenance plan.


4. Commitment

We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.


5. Good Packaging

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
