Uniform Power Splitting Optical Wire Splitter , PLC Splitter 1x16 SC Connector / G657A / 0.1dB PDL

1*16 PLC Optical Fiber Splitter With SC Connector / G657A / 0.1dB PDL

Quick Details:

Model Number: HJ3-1*16 PLCS

Production Standards:: Telcordia GR-1221 and GR-1209

Operating Wavelength:: 1260-1650nm

Connetor Type:: SC,FC,ST,LC or customized

Return Loss:: 50(UPC),55(APC)

PDL:: 0.1dB

Fiber type:: G652.D, G657.A

Specifications

1*16 PLC Splitter for PON

1) PDL 0.1dB

2) RL: UPC:50 APC:55

3) 1260~1650nm

4) ABS box or Micro type

We are professional OEM/ODM manufacturer , until now we have established a long and lasting business relationship with world famous clients such as Siemon , 3M , Emerson , Nexans , Ericssion .Tyco...

PLC Splitter Features:

1.Low Insertion loss

2.Low PDL

3.High Return Loss

4.Uniform Power Splitting

5.Qualified Under Telcordia GR-1221 and GR-1209

PLC Splitter Applications:

1.FTTX (FTTP, FTTH, FTTN, FTTC)

2.PON

3.LAN

4.CATV Systems

PLC Splitter Performance Specifications:

Type		1x2		1×4		1×8		1×16	1×32		1×64		2x2	2×4	2×8	2×16		2×32		2×64
Operating wavelength(nm)		1260-1650
Insertion loss (dB)	Typical	3.6	6.8		10.0		13.0		16.5	20.5		4.0		7.3	10.5	13.5	17.0		20.5
	Maximum	3.8	7.2		10.7		13.9		17.2	22.0		4.2		7.6	10.8	14.0	17.5		22.0
Uniformity (dB)	Typical	0.4	0.5		0.6		1.0		1.0	2.5		0.6		0.8	1.0	1.5	2.0		2.0
	Maximum	0.6	0.8		1.0		1.4		1.6	2.5		0.8		1.0	1.5	2.0	2.5		2.5
Polarization Dependent Loss (dB)	Typical	0.1	0.1		0.15		0.2		0.2	0.2		0.1		0.1	0.1	0.2	0.2		0.2
	Maximum	0.2	0.3		0.3		0.3		0.3	0.3		0.2		0.2	0.3	0.4	0.4		0.4
Wavelength dependent loss (dB)	Typical	0.1	0.1		0.15		0.3		0.3	0.1		0.1		0.1	0.1	0.1	0.2		0.2
	Maximum	0.2	0.3		0.3		0.5		0.5	0.2		0.2		0.2	0.3	0.5	0.5		0.5
Return loss (dB)	Minimum	UPC:50 APC:55
Directivity (dB)	Minimum	55
Operating temperature (°C)		-20 to 70
Storage temperature (°C)		-40 to 85
Optical fiber type		SMF-28e Or customer required
Optical fiber length (m)		1M or customize
Remarks:
1 . Measured at room temperature and excludes connector loss. 2 . For devices with connectors insertion loss will be 0.3 dB higher.

Ordering Information: PLC-A-B/C-D/E-F/G-H

B/C

D/E

F/G

PLC

Port

Input/Output Pigtail Type

Input/Output

Fiber Length

Input/Output Connector

Package

Type

PLC

102=1 x 2

104=1 x 4

108=1 x 8

116=1 x 16

132=1 x 32

164=1 x 64

202=2 x 2

204=2 x 4

208=2 x 8

216=2 x 16

232=2 x 32

1=900um loose tube
2=2.0mm loose tube

3=3.0mm loose tube

05=0.5M

……

10=1.0M

…….

15=1.5M

……

0=None

FU=FC/UPC

FA=FC/APC

SU=SC/UPC

SA=SC/APC

LU=LC/UPC

LA=LC/APC

ST=ST

X=Others

P2=100 x 80 x 10.5

P3=120 x 80 x 18

P4=140 x 115 x 18

XL=1,2,3,4U LGX Module

X=Others
