| Categories | Plastic Blow Moulding Machine |
|---|---|
| Model Number: | 80/90 |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Depends on different model |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 4 sets / 90 days |
| Delivery Time: | 90 days |
| Packaging Details: | Without package or wooden |
| Material: | PE, PP, ABS |
| Grade: | Full Auto |
| Volume: | 30-60L |
| L/D: | 24 |
| Heating Zone: | 4 |
| Warranty: | 1 Year |
| Company Info. |
| Kasmac Industries Co., Ltd. |
| View Contact Details |
| Product List |
30L - 60L Plastic Bottle Moulding Machine , Plastic Injection Blow Molding Machine
Descriptions :
80/90 series automatically blow molding machine adopt diagonal double pull rod center mode-locked clamping system. With hard gear reducer and import inverter and accumulator die head system. Use imported hydraulic valve, seal parts proportional control, human-machine and PLC automatic temperature control model. Optional Japan MOOG parison controller is available.
| Main Technical Parameters | ||
| Specification | 80 Series | 90 Series |
| Material | PE, PP, ABS | |
| Max. Container Capacity (L) | 30 | 60 |
| Dimension (LxWxH) (m) | 4.8x2.3x3.5 | 5.3x2.4x3.8 |
| Weight (T) | 12 | 14 |
| Clamping System | ||
| Clamping Force (kn) | 230 | 320 |
| Platen Opening Stroke (mm) | 400-900 | 450-1050 |
| Platen Size (mm) | 880x915 | 850x950 |
| Move Mould Stroke (mm) | 600x1000 | 870x1200 |
| Min Mould Thickness (mm) | 410 | 460 |
| Hydraulic And Penumatic System | ||
| Motor Power Of Oil Pump (kw) | 18.5 | 23 |
| Air Pressure (Mpa) | 1 | 1 |
| Air Consumption (㎥ /m) | 0.8 | 0.8 |
| Total Power (kw) | 88 | 105 |
| Average Energy Consumption (kw) | 22 | 26 |
| Extruder System | ||
| Screw Diameter (mm) | 80 | 90 |
| L/D | 24 | 24 |
| Plasticing Capacity (kg) | 100 | 140 |
| Number Of Heating Zone (zone) | 4 | 4 |
| Extruder Heating Power (kw) | 20.2 | 21.4 |
| Extruder Driving Power (kw) | 30 | 37 |
| Die-Head | ||
| Number Of Heating Zone (zone) | 4 | 4 |
| Power Of Die Heating (kw) | 15.2 | 21.3 |
| Max. Die Pin Diameter (mm) | 250 | 350 |
| Max. Die Capacity (L) | 5 | 6.6/8 |
|
