2800-3500 pcs/Hrs 18650 Battery Spot Welder HDL6030 Pneumatic Driven

Categories 18650 Battery Spot Welder
Brand Name: AWT
Model Number: HDL6030
Certification: as required
Place of Origin: China
MOQ: 1
Price: negotiable
Payment Terms: T/T
Supply Ability: 50sets per month
Delivery Time: 7-10 days
Packaging Details: Wooden Case
name: pneumatic spot welder
Ball Screw: TBI
linear guide rail: Hiwin
Control System: Smart Controlling system
XY Stroke: 600mm*300mm
Speed: 2800-3500pcs/Hrs
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

2800-3500 pcs/Hrs 18650 Battery Spot Welder HDL6030 Pneumatic Driven

Ebike/E scooter automatic 18650 battery Spot Welder 18650 32650 HDL6030 Pneumatic Driven 2800-3500pcs/Hrs


Used for 18650,26650,32650 cylinder battery pack automatic spot welding

Model: HDL6030 Pneumatic Driven Model 2800-3500pcs/Hrs


Features :


1. Smart controlling system or PLC programming, intelligent interface and Simple Operation

2. First Ladder servo motors and precise linear to ensure accurate welding, stable displacement and long life;

3. Program setting, standard battery mode and special battery mode compatible, can set any spot welding procedure standard, and spot welding electrode horizontal two points and vertical two points compatible, comprehensive consideration, convenient and practical.

4. High spot welding efficiency with 0.3-0.8 seconds / Cycle, speed adjustable with counting function.

5. Stable welding power output


Specification:


Motion platform power input:AC 220V/50HZ
Power consumption:500W
X-axis Stoke:600mm 18650 Max.30PCS, 32650 Max.16PCS
Y-axis Stoke:300mm 18650 Max.16PCS, 2650 Max.9PCS)
Loaded Qty480pcs (standard 18650 lithium battery)
Motor drive stroke:50mm
Positioning cylinder stroke:100mm
Motion module:Ball Screw TBI+Linear Guide Hiwin
Driving mode:Servo Motor Drive
Spot welding efficiency:2800-3500pcs/Hrs
Electrode diameter:∮1.8-2.0mm
Electrode heat dissipation:Forced air cooling
Working pressure:0.2-0.8MPa
Welder power supply:stored energy welder DC Inverter Welder Transistor Welder
Dimension1000mm×1200mm×1800mm
Weight400KG

Notice on AWT Spot Welding Equipments
We only produce high quality machine to ensure the stability and no compromise on quality:
Drive ModeWelding SpeedPrice Level
Pnuematic Drive2800-3500PCS/Hrs(4 Welding Points)Low
Servo Motor Drive3800-4500PCS/Hrs(4 Welding Points)High
Spot WelderInput VoltageNickel ThicknessPrice Level
Stored Energy WelderAC 220V/50HZ 5000ANickel Alloy≦0.2mm Pure Nicel≦0.15mmLow
DC Inverter WelderAC 380V/50HZ 5000ANickel Alloy≦0.2mm Pure Nicel≦0.15mmMiddle
DC Inverter WelderAC 380V/50HZ 8000APure Nicel≦0.2mm,slot Nickel≦0.4mmHigh
Transistor WelderPD-6000A/10000APure Nicel≦0.2mm,slot Nickel≦0.4mmExpensive
