| Categories | Air Pressure Sensor |
|---|---|
| Brand Name: | WNK |
| Model Number: | WNK83MA |
| Certification: | ISO, CE |
| Place of Origin: | China |
| MOQ: | 1 piece |
| Price: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Piece/Pieces per Month |
| Delivery Time: | 5-7 working days |
| Packaging Details: | Standard export carton box or according to your requirement |
| Accuracy: | 1%F.S |
| Output: | 0.5-4.5V |
| Pressure range: | 0-1000Kpa |
| Power supply: | 4.75-5.25VDC |
| Work temperature: | -20~70°C |
| Measured media: | Liquid, gas, steam |
| Housing material: | Brass |
| Electrical connection: | Cable outlet |
| Company Info. |
| Hefei WNK Smart Technology Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Parameter
| Applicable media | Liquid, gas, steam |
| Pressure range | 0-1000Kpa |
| Pressure measurement | Gauge pressure, sealing pressure |
| Output | 0.5-4.5V |
| Power Supply | 4.75-5.25VDC |
| Accuracy(lineraity, hysteresis, repeatability) | 1%FS |
| Work temperature | -20~70°C |
| Storage temperature | -40~110°C |
| Temp drift(zero) | ±0.15%FS(-20~70°C) |
| Temp drift(full range) | ±0.15%FS(-20~85C) |
| Electrical connection | Parkard |
| Mechanical connection | Cable outlet |
| Housing material | Brass |
Mechanical Dimension
Q: Are you manufacturer or trading company?
A: We are professional pressure/level/temperature measurement manufacturer since 2004.
Q: What’s your quality control system?
A: We are an ISO 9001-2015 certified manufacturer, we have strict quality control system. Besides clibartiaon, each set product we also do temperature compensation and aging test before shipment, so the quality is guaranteed.
Q: What is the warranty of your products?
A: 12 month from shipment date, for non-man-made damages.
Q: Can we use our logo on the products? Do you provide customized products?
Yes.we can use your logo, we can provide customized products per requirement. OEM/ODM is welcome
Q: What is yor MOQ?
A: We have no MOQ limits, small quantity order is acceptable.
Q: What's the transport?
A: Express such as DHL, Fedex, TNT, UPS for freight prepaid, also can use your own couier account to do the freight collect. For more goods we can arrange by air or by Sea.
|
