| Brand Name: | FASTPCBA |
| Model Number: | SMT PCBA Assembly Services |
| Certification: | ISO13485, IATF16949, ISO9001 |
| Place of Origin: | China |
| MOQ: | 1PCS |
| Price: | USD 0.1-3/ pcs |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Packaging Details: | 1.Inner: PCB: Vacuum Packing PCBA: ESD Packing 2.Outer: Standard export carton 3.Customized package. |
| Service: | One-stop Service |
| Layer Count: | 1-48 |
| Testing Service: | Function Test, 100% Test |
| Min line/space: | 0.075/0.075mm |
| Silkscreen: | Min size 0.006″(0.15mm) |
| Min solder mask clearanace: | 0.003”(0.07mm) |
| Company Info. |
| FASTPCBA Co., Ltd. |
| View Contact Details |
| Product List |
Technical Requirement for pcb assembly:
1) Professional Surface-mounting and Through-hole soldering
Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line.
7) High density interconnected board placement technology capacity.
Production Requirement for pcb assembly:
1. Gerber Files (Eagle and PCB File are available).
2. BOM list.
3. Clear pictures of PCBA or PCBA samples to us.
4. Pick N Place file.
5. Test procedure for PCBA.
1.Detailed Specification of PCB Board Manufacturing
| 1 | Layer | 1-48 layer |
| 2 | Material | FR-4,CEM-1,CEM-3,Hight TG,FR4 Halogen Free,FR-1,FR-2,Aluminum |
| 3 | Board thickness | 0.4mm-4mm |
| 4 | Max.finished board side | 700mm*460mm |
| 5 | Min.drilled hole size | 0.25mm |
| 6 | Min.line width | 0.10mm(4mil) |
| 7 | Min.line spaceing | 0.10mm(4mil) |
| 8 | Surface finish/treatment | HASL/HASL lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating |
| 9 | Copper thickness | 1/2OZ 1OZ 2OZ 3OZ |
| 10 | Solder mask color | green/black/white/red/blue/yellow |
| 11 | Inner packing | Vacuum packing,Plastic bag |
| 12 | Outer packing | Standard carton packing |
| 13 | Hole tolerance | PTH:±0.076,NTPH:±0.05 |
| 14 | Certificate | IATF16949, ISO13485, ISO9001 |
| 15 | Profiling Punching | Routing,V-CUT,Beveling |
| 16 | Assembly Service | Providing OEM service to all sorts of printed circuit board assembly |
2.Detailed Terms for PCB Assembly
| Technical Requirement | Professional Surface-mounting and Through-hole soldering Technology |
| Various sizes like 1206,0805,0603 components SMT technology | |
| ICT(In Circuit Test),FCT(Functional Circuit Test) technology | |
| PCB Assembly With UL,CE,FCC,Rohs Approval | |
| Nitrogen gas reflow soldering technology for SMT | |
| High Standard SMT&Solder Assembly Line | |
| High density interconnected board placement technology capacity | |
| Quote&Production Requirement | Gerber File or PCB File for Bare PCB Board Fabrication |
| Bom(Bill of Material) for Assembly,PNP(Pick and Place file) and Components Position also needed in assembly | |
| To reduce the quote time, please provide us the full part number for each components,Quantity per board also the quantity for orders. | |
| Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate | |
| OEM/SMT/EMS Services | PCBA, PCB assembly: SMT & PTH & BGA |
| PCBA and enclosure design | |
| Components sourcing and purchasing | |
| Quick prototyping | |
| Plastic injection molding | |
| Metal sheet stamping | |
| Final assembly | |
| Test: AOI, In-Circuit Test (ICT), Functional Test (FCT) | |
| Custom clearance for material importing and product exporting | |
| Other PCB Assembly Equipments | SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4 |
| Reflow Oven: FolunGwin FL-RX860 | |
| Wave Soldering Machine: FolunGwin ADS300 | |
| Automated Optical Inspection (AOI): Aleader ALD-H-350B,X-RAY Testing Service | |
| Fully Automatic SMT Stencil Printer: FolunGwin Win-5 |
FASTPCBA is the independent export pcba assembly factory over 20 years, who are recognized as the top 10 pcba manufactuerer global, serving for customers of safety protection pcba, automotive circuit board, medical pcba, industrial pcba, communication pcba, smart home pcba, aviation pcba and military pcba etc.
|
ISO13485 Electronic Turnkey PCB Assembly Electronic Assembly Fabrication
ENIG Fr4 Heavy Copper Turnkey PCB Assembly Assembled Printed Circuit Boards Production
One Stop Reverse Engineering Turn Key Pcb Assembly Contract Electronic Assembly
Large Batch Prototyping Turnkey PCB Assembly Manufacturing Rapid Pcba
Rapid Prototyping Pcb Assembly Testing PCBA Service Aluminum PCB Prototyping
Fast Quotation Flex Turnkey PCB Assembly Through Hole Printed Circuit Board
ISO 13485 Certified Healthcare Medical Pcb Assembly Custom Electronics
Contract Fast Turnkey PCB Assembly Rapid Pcba Circuit Card Assembly
1 To 48 Layers Rigid Flexible Turnkey PCB Assembly Pcba Ball Grid Array Assembly
Automated Bga Quick Prototype Turnkey PCB Assembly Pcba Board
