| Categories | On Grid Solar Inverters |
|---|---|
| Brand Name: | king sun |
| Model Number: | GT-15kw |
| Certification: | CE,SGS,TUV,IEC,CQC, |
| Place of Origin: | china |
| MOQ: | 1PCS |
| Price: | $930 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | Production of 500 inverters per day |
| Delivery Time: | 7 |
| Packaging Details: | paper skin+wood pallet |
| Weight: | 14Kgs |
| Type: | DC/AC Inverters |
| Output frequency: | 50Hz/60Hz |
| Output voltage: | 110v/220V/230V/240V |
| Application: | home use,Frequency change,Solar Power System Home,Grid Tie Solar Panel System |
| Display: | LCD Display |
| Output waveform: | Pure Sine Wave Output |
| Frequency: | 50-65Hz |
Growatt GOODWE Solar Inverter 3kw 4kw 5kw 6kw 7kw 8kw 10kw on grid solar inverter manufacturer
| GT-20kW-B | GT-17KW-B | GT-15KW-B | GT-12KW-B | ||
| Efficiency | Max efficiency | 98.50% | 98.43% | 98.30% | 98.20% |
| Euro efficiency | 98.10% | 98.00% | 97.90% | 97.80% | |
| MPPT | 99.90% | 99.90% | 99.90% | 99.90% | |
| PV port | Absolute maximum PV input voltage | 1050V | 1050V | 1050V | 1050V |
| Start-up voltage | 180V | 180V | 180V | 180V | |
| Rated PV input voltage | 630V | 630V | 630V | 630V | |
| MPPT range for full load | 450V-800V | 450V-800V | 450V-800V | 500V-850V | |
| Operating MPPT voltage range | 200V-1000V | 200V-1000V | 200V-1000V | 200V-950V | |
| Number of independent MPPT | 2pcs(2+2)pcs | 2pcs(2+2)pcs | 2pcs(2+1)pcs | 2pcs(1+1)pcs | |
| MaxPV input current for each MPPT | 23A23A | 23A23A | 23A12A | 12A | |
| Max input short circuit current for each MPPT | 28A28A | 28A28A | 28A15A | 15A | |
| Output AC | Nominal AC power | 20000W | 17000W | 15000W | 12000W |
| Absolute maximum AC power | 21500VA | 18800VA | 16500VA | 14000VA | |
| Rated grid voltage/grid connected voltage range | 400V(230V)270V-480V | ||||
| Grid type | 3LNPE | 3LNPE | 3LNPE | 3LNPE | |
| Nominal grid current | 31A | 28A | 23A | 20.3A | |
| Rated grid frequency | 50Hz60Hz 45Hz-55Hz55Hz-65Hz | ||||
| Output THDi | <3% | <3% | <3% | <3% | |
| Dc component | <0.5%*In | <0.5%*In | <0.5%*In | <0.5%*In | |
| Nominal power factor and adjustable range | 1 and 0.8 leading-0.8 lagging | ||||
| Protection | Dc switch | Y | Y | Y | Optional |
| Output over current protection | Y | Y | Y | Y | |
| Anti-islanding protection | Y | Y | Y | Y | |
| Current surge protection | DC level 2AC level3 | ||||
| Dc reverse | Y | Y | Y | Y | |
| Residual current | Y | Y | Y | Y | |
| Insulation resistor detection | Y | Y | Y | Y | |
| Current overvoltage protection | Y | Y | Y | Y | |
| General data | Dimensions(W/H/D)mm | 505420210 | |||
| Weight | 25kg | 25kg | 23kg | 20kg | |
| IP grade | IP65 | IP65 | IP65 | IP65 | |
| Mounting | Wall bracket | Wall bracket | Wall bracket | Wall bracket | |
| Cooling | Wind cooling | Wind cooling | Wind cooling | Wind cooling | |
| Isolation level | Transformerless | Transformerless | Transformerless | Transformerless | |
| Standby consumption | <15W | <15W | <12W | <10W | |
| Ambient temperature | -30℃-60℃(derating at 45℃) | ||||
| Relative humidity | 0~100% | ||||
| Operating altitude | <3500m,derating at 2000m | ||||
| Display/monitoring | LED | ||||
| Communication | GPRSWIFI | ||||
| AC/DC connection | Plug | ||||
| Standard | Safety | IEC62109-1/-2,IEC62116,IEC61727 | |||
| EMC | EN61000-6-2, EN61000-6-3 | ||||
| Grid | AS4777.2,NBIT 32004-2018 | ||||
