4 Channel 2m 40G QSFP+ DAC Cable For InfiniBand 4XSDR

Categories DAC Direct Attach Cable
Brand Name: YXFiber
Model Number: DAC
Certification: CE RoHS FCC
Place of Origin: Hubei, China
MOQ: 1pcs
Price: $13.00 - $16.00 / Piece
Payment Terms: T/T
Supply Ability: 100000pcs per month
Delivery Time: 1~3working days after payment
Packaging Details: 10pcs in Plastic tray
Type: Fiber Optic Transceivers
No. of Fiber: 4.
Use: FTTH
Distance: 2m
Max Data Rate: 40Gbps
Voltage Supply: 3.3V~5.5V
Low/High Case Temperature: perature: 0°C~70°C
Port: Wuhan
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

4 Channel 2m 40G QSFP+ DAC Cable For InfiniBand 4XSDR

Product Description

40G QSFP+ TO 4SFP+ DAC PASSIVE Direct Attach Copper Cable

The QSFP+ passive cable assemblies are high performance,cost effective I/O solutions for 40G LAN, HPC and SAN applications. The QSFP+ passive copper cables are compliant with SFF-8436, QSFP+ MSA and IEEE P802.3ba 40GBASE-CR4. It is offer a low power consumption,short reach intercon- nect applications. The cable each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s

Product Features :
* QSFP+ conforms to the Small Form Factor SFF-8436
* 4-Channel Full-Duplex Passive Copper Cable Transceiver
* Support for multi-gigabit data rates :1.0 Gbps – 10.3125 Gbps (per channel)
* Maximum aggregate data rate: 41.25 Gps (4 x 10.3125Gbit/s)
* Copper link length up to 5m (passive limiting)
* High-Density QSFP 38-PIN Connector
* Power Supply :+3.3V
* Low power consumption: 0.02 W (typ.)
* I2C based two-wire serial interface for EEPROM signature which can be customized
* Operating case temperature:
Standard : 0 to +70°C(default) Industrial : -40 to +85°C
* RoHS Compatible

Product Application :

* 10G/40Gigabit Ethernet
* InfiniBand 4XSDR, DDR, QDR
* Switches, Routers, and HBAs
* Data Centers
* 2, 4, 8, 10 Gigabit Fibre Channel

Parameter

Package (Form Factor)QSFP-4SFP+ Copper Cable
Data Rate (typical)10.3 Gbps/CH
Distance2m
Low/High Case Temperature0°C~70°C
Voltage Supply (typical)3.3v
ConnectorQSFP SFP+
Application
