Multimode Optical Fiber Media Converters UTP With 1K MAC Address Table

Multimode Optical Fiber Media Converter UTP With 1K MAC Address Table

Quick Details:

1. Place of Origin: Guangdong, China (Mainland)

2. Brand Name: DYS

3. Model Number: Single multimode converter Repeaters - 1

4. Certifaction: ISO9001, ROHS

Fiber Optic Media Converter Specifications

Operating standard:

IEEE802.3 10BASE-T Ethernet
IEEE802.3u 100BASE-TX/FX Fast-Ethernet
IEEE802.3x

1. Data Buffer :128Kb RAM

2. MAC address table: 1K

3. Connector: UTP: RJ-45, 10/100Mbps; Fiber: SC, 100Mbps

Cable:

UTP: Cat. 5 UTP (the max distance up to100m)

Fiber ( Singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm(the max distance up to 90km)

1.Flow control

Full Duplex:IEEE802.3x

HalfDuplex:back pressure

2.LED: Power, FX 100, FX Link/Act, TX 100, TX FDX, TX Link/Act.

3.Power :Input:AC 110~265V or DC:-36V~-72V

Output:DC 12-24V 1A

4.Conversion mode: Medium conversion

5.MTBF: 80, 000 hours

6.Ambient temperature:0 ～+50℃

7.Storage temperature:-20 ～+70℃

8.Humidity:5% ～95%

Dimensions:

Power external: 26 (high) x 70 (width) x 94 (length) mm

Power internal : 30 (high) x 110 (width) x 140 (length) mm

Main features

1.The transmission of a channel optical signals can be completed by single fiber. It has doubled in quantity of fiber data transmission compared with twin fiber type.

2.Auto negotiation function allows UTP port to auto select 10M or 100M and Full Duplex or Half Duplex

3.UTP port supports MDI / MDI-X auto crossover.

4.Supporting flow control

5.Supporting 1552 bytes packet

6.Extend fiber distance up to 2km for multi-mode fiber and 20-120km for single-mode fiber

7.Internal circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.

8.Supports link fault pass through function

9.Design of internal or external power supply for selection by end-users
